Description
The Eaton Tripp Lite B093-008-2E4U-M 8-Port Console Server is a secure, enterprise-grade solution designed to provide in-band and out-of-band remote access to serial-based networking equipment. With dual Gigabit Ethernet ports for redundancy and a built-in V.92 modem, it ensures reliable connectivity even during primary network outages.
Engineered for maximum accessibility, it supports up to eight RS-232 serial console ports via standard Cat5e/6 cabling and integrates seamlessly with TACACS+, RADIUS, LDAP, and Kerberos authentication systems. Its 4GB internal NAND flash, dual SFP ports, and USB 2.0 console ports expand versatility for managing routers, switches, firewalls, PDUs, and UPS systems.
Built with robust security protocols, including PCI DSS 3.2, FIPS 140-2, SSL/SSH, and VPN (OpenVPN/IPSec) support, the B093-008-2E4U-M guarantees data protection for sensitive environments. The fanless steel design allows for quiet, reliable performance in rack or desktop installations, while compliance with TAA and RoHS standards ensures suitability for government and enterprise deployments.
| Category | Specification |
|---|---|
| Model Number | B093-008-2E4U-M |
| Form Factor | 1U Rackmount / Desktop |
| Ports | 8 x RJ45 Serial (RS-232); 2 x RJ45 Gigabit Ethernet; 2 x SFP; 4 x USB 2.0 Type-A; 1 x RJ11 (Modem) |
| Network Speed | 1 Gbps (Gigabit Ethernet) |
| Security Protocols | SSL, SSH, FIPS 140-2, PCI DSS 3.2, OpenVPN, IPSec VPN |
| Authentication | TACACS+, RADIUS, LDAP, Kerberos |
| Modem | Built-in V.92 Serial Data/Fax Modem |
| Internal Storage | 4GB NAND Flash |
| Power Input | 100–240V AC, 50/60Hz, 0.4A (via AC Adapter, 12V / 1.25A Output) |
| Power Consumption | 11.5 Watts |
| Power Source | External AC Adapter (Included) |
| Material | Metal (Black Finish) |
| Dimensions (H x W x D) | 1.4 x 5.1 x 4.7 in (3.56 x 16.51 x 10.16 cm) |
| Weight | 1.3 lbs (0.59 kg) |
| Operating Temperature | -13°F to 140°F (-25°C to 60°C) |
| Storage Temperature | -40°F to 167°F (-40°C to 75°C) |
| Humidity | 5–90% RH (Non-Condensing) |
| Certifications | CE, FCC, UL, cUL, TUV, PSE, C-Tick, GS, RoHS, REACH, CB, TAA-Compliant |
| LED Indicators | Power, Heartbeat, Serial Connectivity, Network Ports |
| Mounting Options | EIA-Standard 19" Rack or Desktop (Rubber Feet Included) |
| Warranty | 4-Year Limited Warranty |
