Description
The Eaton Tripp Lite BP36V42-3U external battery pack extends the runtime of compatible 36V DC UPS systems, ensuring your critical equipment stays protected during outages. Engineered for flexibility, it supports both rack-mount (3U) and tower configurations. The unit includes a heavy-duty DC connector cable for safe and easy integration, plus a daisy-chain connector to link additional battery packs for even greater runtime.
Pre-installed mounting hardware supports 4-post racks, with optional accessories available for 2-post or wall-mount installations. Compatible with Eaton UPS models such as SMART1000RMXL2U, SMART1500RMXLN, and others requiring a 36V external battery connection.
| Specification | Details |
|---|---|
| Model Number | BP36V42-3U |
| Battery Type | External battery pack for 36V DC UPS systems |
| Battery Voltage | 36 VDC |
| Expandable Runtime | Yes (daisy-chain capable) |
| UPS Connection | Detachable DC cable, 36" length, 6-gauge |
| Typical Battery Lifespan | 4–6 years (North America) |
| Form Factor | Rack/Tower (3U height) |
| Mounting Options (Included) | 4-post 19-inch rackmount (brackets included) |
| Mounting Options (Optional) | 2-post center-mount & wall-mount (with 2POSTRMKITWM) |
| Unit Dimensions (H x W x D) | 5.25 x 17.5 x 25 in (13.3 x 44.45 x 63.5 cm) |
| Shipping Dimensions (H x W x D) | 12 x 23 x 33 in (30.48 x 58.42 x 83.82 cm) |
| Unit Weight | 174.1 lbs (78.97 kg) |
| Shipping Weight | 185 lbs (83.91 kg) |
| Material | Steel |
| Rack Height | 3U |
| Minimum Required Rack Depth | 28 in (71.12 cm) |
| Certifications | RoHS, CE |
| Warranty (U.S. & Canada) | 2-year limited |
| Warranty (International/Mexico/Puerto Rico) | 1-year limited |
