Description
The Eaton Tripp Lite N482TAP-4MM73M8 is a high-performance OM4 multimode fiber TAP (Traffic Access Point) cassette designed for real-time network monitoring and analysis. Its 70/30 optical split enables 70% of the light signal to continue through the primary link while directing 30% to a monitoring device, providing passive, latency-free access to data traffic. Ideal for data centers, telecom environments, and R&D facilities, it supports 40/100/400Gbps parallel optics for uncompromised network visibility.
Engineered for use with Eaton’s N482-Series chassis, the modular cassette features 8-fiber MPO/MTP connectors for quick deployment and easy integration with Base-8 cabling systems. Factory-terminated and OM4-rated, it ensures low insertion loss and full compliance with IEEE 802.3ae and ANSI T11.2 standards, offering reliability, durability, and precision for advanced optical network monitoring applications.
| Category | Specification |
|---|---|
| Model Number | N482TAP-4MM73M8 |
| Product Type | Passive Fiber TAP Cassette |
| Technology | Multimode (OM4) |
| Optical Mode | OM4, Base-8 Connectivity |
| Network Compatibility | 40 Gbps / 100 Gbps / 400 Gbps |
| Split Ratio | 70/30 (70% User / 30% Monitoring) |
| Wavelength | 850 nm |
| Insertion Loss | 3.00 dB / 7.00 dB @ 850 nm |
| Monitoring Ports | 4 × MTP/MPO (Male) |
| Input Ports | 4 × MTP/MPO (Male) |
| Output Ports | 4 × MTP/MPO (Male) |
| Number of Fibers | 32 |
| Compatible Enclosures | N482-00U (1 Cassette), N482-01U (5), N482-02U (14), N482-04U (28) |
| Dimensions (H × W × D) | 1.18 × 4.72 × 3.46 in |
| Shipping Dimensions (H × W × D) | 2.00 × 7.90 × 4.70 in |
| Shipping Weight | 0.44 lb |
| Operating Temperature | -4°F to 140°F (-20°C to 60°C) |
| Storage Temperature | -4°F to 140°F (-20°C to 60°C) |
| Relative Humidity | 5% – 85% (Non-Condensing) |
| Compliance Standards | IEEE 802.3ae, ANSI T11.2, RoHS, REACH |
| Warranty | Lifetime Limited Warranty |
