Description
The B162-100-POE HDMI over IP Receiver delivers visually lossless 4K video with ultra-low latency over standard Cat5e/6 cabling or a Gigabit Ethernet network. Designed for scalable AV deployments, it supports point-to-point and multipoint-to-multipoint configurations without distance limitations when used over a LAN.
With Power over Ethernet (PoE) support, the receiver can be installed in locations without nearby AC outlets, making it ideal for digital signage, video walls, conference facilities, campuses, airports, and trade show environments. Advanced lightweight compression preserves image quality up to 4K @ 30Hz with 4:4:4 chroma, while web-based management enables fast configuration, monitoring, and layout control.
TAA compliance and enterprise-grade reliability make the B162-100-POE a strong choice for government, education, and commercial AV applications.
| Category | Specification |
|---|---|
| Product Type | HDMI over IP Receiver |
| Model | B162-100-POE |
| Video Resolution | Up to 3840 × 2160 (4K) @ 30Hz |
| Chroma Subsampling | 4:4:4 |
| Video Compression | Lightweight, visually lossless |
| Max Distance | 328 ft (100 m) over Cat6 |
| Network Support | Gigabit Ethernet (LAN-based transmission) |
| Power Options | Power over Ethernet (PoE) or external power supply |
| Power Consumption | 4.36 W (PoE), 3.49 W (DC) |
| Video Outputs | 1 × HDMI |
| Audio Support | De-embedded audio via 3.5 mm output |
| Control Interfaces | Ethernet, RS-232, USB, IR |
| Video Wall Support | Up to 8 × 8 (64 displays) |
| Daisy-Chain Support | Yes, up to 30 units |
| Management | Web GUI, CLI (Telnet/TCP), RS-232 |
| HDCP | HDCP 1.4 |
| Mounting | Rack-mountable |
| Construction | Metal enclosure |
| Compliance | TAA, CE, FCC, RoHS, REACH |
| Operating Temperature | 32° to 104°F (0° to 40°C) |
| Warranty | 1-Year Limited |
