Description
The Tripp Lite SmartRack SRW18UHD is an 18U heavy-duty, low-profile wall-mount rack enclosure designed for secure server-depth installations in space-constrained environments. Its side-mount, low-profile design extends less than 25 inches from the wall while supporting equipment up to 32.5 inches deep, making it ideal for network wiring closets, classrooms, retail back offices, and IT utility spaces.
Constructed from durable steel with a black powder-coated finish, this enclosure supports up to 500 lb of equipment, including servers, UPS systems, battery packs, network switches, and patch panels. Locking front and side panels protect valuable hardware, while vented top, bottom, and side panels promote airflow for reliable cooling.
Shipped fully assembled for quick installation, the SRW18UHD features adjustable vertical mounting rails with both square-hole and 12-24 threaded mounting options. Integrated cable routing ports on the top and bottom simplify cable management while maintaining a clean, professional installation.
| Specification | Details |
|---|---|
| Brand | Tripp Lite |
| Model | SRW18UHD |
| Rack Height | 18U |
| Rack Width | 19-inch EIA standard |
| Mount Type | Side-mount wall-mount enclosure |
| Profile | Low-profile, server-depth |
| Maximum Load Capacity | 500 lb (227 kg) |
| Maximum Equipment Depth | 32.5 in (826 mm) |
| Minimum Equipment Depth | 3 in (76 mm) |
| Extension From Wall | Less than 25 in |
| Mounting Rails | 4 vertical rails, adjustable |
| Rail Hole Type | Square holes and 12-24 threaded |
| Rail Adjustment | 7/8-inch increments |
| Construction | Heavy-duty steel |
| Finish | Black powder coat |
| Ventilation | Vented top, bottom, and sides |
| Security | Locking front panel and side doors |
| Cable Access | Top and bottom cable routing ports |
| Assembly | Ships fully assembled |
| Compliance | EIA-310-E, RoHS |
| Typical Applications | Servers, UPS, switches, patch panels |
