Description
The Eaton Tripp Lite SRN4G12US SmartRack Industrial Enclosure provides durable, secure, and weather-protected housing for your critical rack-mounted equipment. Designed for rugged environments, it features a NEMA 4-rated, powder-coated steel construction that safeguards against water, ice, dust, and debris—ideal for industrial, utility, and transportation settings.
This 12U wall-mount enclosure supports up to 200 lbs (91 kg) of equipment up to 28 inches deep, such as network switches, PDUs, patch panels, or UPS systems. Its locking, gasket-sealed door ensures security and environmental protection, while the hinged design offers easy back-door access for installation and maintenance. Adjustable mounting rails and pre-assembled construction make setup straightforward and reliable.
Built for both indoor and outdoor applications, the SRN4G12US is the ideal solution for keeping sensitive electronics safe, organized, and protected in demanding conditions.
| Category | Details |
|---|---|
| Brand | Eaton Tripp Lite |
| Model | SRN4G12US |
| Rack Type | Wall-Mount Enclosure |
| Rack Height | 12U |
| Rack Depth | Up to 28 in. (71.12 cm) |
| Material | Powder-Coated Steel |
| Color | Gray |
| Mounting Location | Wall |
| Lock Type | Keyed Lock |
| Protection Rating | NEMA 4 |
| Weight Capacity (Stationary) | 200 lbs (91 kg) |
| Unit Dimensions (H x W x D) | 24.08 x 24.00 x 30.05 in. (61.16 x 61.16 x 76.33 cm) |
| Shipping Weight | 175 lbs (79.38 kg) |
| Door Type | Hinged, Gasket-Sealed |
| Cable Entry | Sealed cut-out (compatible with gland plates) |
| Outdoor Use | Yes |
| Grounding | Cabinet Body |
| Certifications | UL 508A, CAN/CSA-C22.2 No. 286 |
| Compliance | EIA/ECA-310-E, NEMA 4, RoHS, REACH |
| Warranty | 5-Year Limited Warranty |
| Typical Applications | Industrial, factory, power station, warehouse, transport terminal |
| Included Accessories | (48) 10-32 screws, (48) M6 washers, (4) LDPE plugs, (4) M10 foam washers, (2) Keys, Owner’s manual |
