Description
The Edgecore AS5916-54XL (AGR110) is a high-performance aggregation router built for cloud data centers and carrier networks. Powered by the Broadcom StrataDNX® Qumran MX™ chipset and an Intel® Xeon® D-1518 quad-core processor, it delivers line-rate Layer 2 and Layer 3 switching performance of up to 800 Gbps.
Designed for flexibility, the AS5916-54XL offers 48 x 10G SFP+ ports and 6 x 100G QSFP28 uplink ports, enabling deployment as a data center Top-of-Rack (ToR) or carrier access/aggregation switch. It supports IEEE 1588v2 and SyncE for timing synchronization and features redundant, hot-swappable dual AC power supplies and 5+1 fan modules for high availability.
Pre-loaded with ONIE (Open Network Install Environment), the switch provides the freedom to load open-source or commercial network operating systems such as Open Network Linux (ONL), making it ideal for open networking environments.
| Category | Details |
|---|---|
| Model | AS5916-54XL (AGR110) |
| Part Number (SKU) | 5916-54XL-OT-AC-F |
| Switching Capacity | 800 Gbps |
| Forwarding Rate | 700 Mpps |
| Processor | Intel® Xeon® D-1518, 4-Core, 2.2 GHz |
| Memory | 16 GB DDR4 (8 GB x 2) |
| Storage | 128 GB M.2 SSD (MLC) |
| Switch Silicon | Broadcom® BCM88370 Qumran MX™ |
| Ports | 48 x SFP+ (1/10 GbE), 6 x QSFP28 (40/100 GbE) |
| Management Ports | 1 x RJ-45 Console, 1 x RJ-45 Mgmt, 1 x USB, 1 x BMC |
| Supported Optics & Cables | 10GBASE-CR/SR/LR, 40GBASE-CR4/SR4/LR4, 100GBASE-SR4/LR4 |
| Airflow | Front-to-Back |
| Power Supply Units | Dual, load-sharing, hot-swappable AC PSUs |
| Input Power | 100–240 VAC |
| Cooling | 5+1 hot-swappable redundant fans |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Operating Humidity | 5% to 95% non-condensing |
| Dimensions (W x D x H) | 438.4 × 501.9 × 44 mm (17.26 × 19.76 × 1.73 in) |
| Weight | 9.7 kg (21.38 lb) |
| Software Environment | ONIE pre-loaded; compatible with Open Network Linux (ONL) |
| Regulatory Compliance | CE, FCC Part 15 Class A, UL/CUL, CB, VCCI Class A, NEBS Level 3, RoHS 2.0, WEEE |
| Warranty | 3-Year Limited Hardware Warranty |
