Description
The Infortrend EonStor DS 3000U DS3024SUC000J is a high-availability enterprise SAN storage system designed for performance-critical workloads. Built in a 4U 24-bay chassis, this model features a single controller architecture that is upgradeable to redundant controllers, allowing organizations to scale availability as requirements grow.
Optimized for high IOPS environments, the system includes 12Gb/s SAS expansion connectivity, integrated 1GbE iSCSI ports, and flexible host board expansion slots to support a wide range of block-level protocols. Advanced data services such as snapshots, thin provisioning, and replication help ensure data protection and operational efficiency across mixed workloads.
With support for up to 448 drives via expansion enclosures, modular hot-swappable components, and enterprise-grade RAID protection, the EonStor DS 3000U provides a future-ready storage foundation for virtualization, databases, and mission-critical applications.
| Specification | Details |
|---|---|
| Product Series | EonStor DS 3000U |
| Model | DS3024SUC000J |
| Form Factor | 4U Rack-Mount |
| Drive Bays | 24 |
| Supported Drive Types | 2.5" SAS/SATA SSD, 2.5" SAS HDD, 3.5" NL-SAS HDD |
| Controller Configuration | Single controller, upgradeable to redundant |
| Cache Memory | 64 GB DDR4 (2 × 32 GB) |
| Cache Protection | Super Capacitor + Flash Module |
| Onboard Host Ports | 4 × 1GbE iSCSI |
| Expansion Ports | 1 × 12Gb/s SAS |
| Host Board Slots | 2 |
| RAID Levels Supported | RAID 0, 1, 3, 5/5F, 6/6F, 10, 30, 50, 60 |
| Maximum Drive Support | Up to 448 drives with expansion |
| Supported Protocols | iSCSI, SAS, Fibre Channel (via host boards) |
| Data Services | Thin provisioning, snapshots, replication, SED |
| Power Supplies | Dual redundant hot-swappable 460W (80 PLUS Bronze) |
| Cooling | Redundant hot-swappable fan modules |
| Management | Web-based SANWatch, RAIDWatch, CLI |
| Dimensions (W × H × D) | 449 × 174.4 × 500 mm |
| Weight (without drives) | 27.44 kg |
