Description
Experience ultimate performance and flexibility with the Epson EB-PU2220B, Epson’s most advanced large venue projector designed for live events, auditoriums, and large-scale installations. Delivering an astonishing 20,000 lumens of equal color and white brightness, this compact and energy-efficient projector ensures vibrant, crisp visuals in any environment.
The EB-PU2220B features WUXGA resolution with 4K Enhancement, supporting 4K content and producing up to 4.6 million pixels on screen for lifelike clarity. Designed with reliability in mind, it incorporates a virtually maintenance-free 20,000-hour laser light source, a filterless cabinet, and a sealed IP5X-rated optical engine for superior dust resistance.
Installation is seamless with nine optional powered lenses (sold separately), including an ultra short throw .35 lens with zero-offset design. For live events, the projector is optimized with 3G-SDI input/output for daisy-chaining, long cable runs, and a mechanical shutter for protection during laser shows.
Additional features include HDR support, high native contrast ratio, NFC setup, and compatibility with the optional PixAlign™ camera for advanced tools like color calibration, stacking, and blending. Compact, lightweight, and powerful, the EB-PU2220B is the professional choice for demanding projection environments.
| Feature | Specification |
|---|---|
| Brand | Epson |
| Model | EB-PU2220B |
| SKU | V11HA66820 |
| Projection System | 3-chip 3LCD technology |
| Native Resolution | WUXGA with 4K Enhancement (1920 x 1200 x 2) |
| Display Resolution | Up to 4096 x 2160 (resizing) |
| Brightness (Color/White) | 20,000 lumens |
| Contrast Ratio | 5,000,000:1 (Dynamic) |
| Aspect Ratio | Supports 4:3, 16:10, 16:9, 21:9 |
| Color Reproduction | Up to 1.07 billion colors |
| Light Source | Laser diode, 20,000-hour virtually maintenance-free |
| Lens Options | 9 optional powered lenses (sold separately) |
| Lens Shift | Vertical ±60%, Horizontal ±18% |
| Throw Ratio Range | 1.57 – 2.56 (with ELPLM15 lens) |
| Keystone Correction | Vertical ±45°, Horizontal ±30° |
| Connectivity | 3G-SDI in/out, HDMI (HDCP 2.3), HDBaseT, DVI-D, VGA, USB-A/B, RS-232c, RJ-45 network |
| Audio Out | Variable audio out (mini stereo) |
| Power Requirements | 100–120 V AC / 200–240 V AC, 50/60 Hz |
| Power Consumption | 1,301 W (Normal, 220 V) / 899 W (Quiet) |
| Noise Level | 45 dB (Normal), 37 dB (Eco) |
| Dimensions (W x D x H) | 23.1" x 19.4" x 8.6" (including feet) |
| Weight | 53.7 lb (24.4 kg) |
| Control & Setup | NFC, Epson Projector Configuration Tool, Epson Projector Professional Tool app |
| Eco Features | RoHS compliant, SmartWay® Transport Partner, end-of-life recycling options |
| Warranty | 3-year limited warranty; optional extended service plans up to 5 years |
| Included Accessories | EB-PU2220B projector, 120 V & 220 V power cables, remote control with batteries, cable cover, quick reference guide, warranty sheet |
