Description
The ASUS ESC4000 G3S is a high-performance 2U rack-mountable server barebone engineered for enterprise and HPC workloads. Powered by the Intel® C612 chipset and supporting up to two LGA2011-v3 CPUs, this platform delivers exceptional computing scalability for virtualization, data analytics, and AI inference.
Designed for flexibility and efficiency, the ESC4000 G3S accommodates up to 16 DDR4 DIMMs (max 1 TB) with quad-channel memory architecture, offering the bandwidth and capacity to handle memory-intensive applications. Six hot-swap 2.5" SATA drive bays provide streamlined storage management, while redundant 1620 W 80 PLUS Platinum power supplies ensure operational stability and uptime.
Its intelligent remote management capabilities—via the included ASMB8-iKVM card—enable administrators to monitor, manage, and troubleshoot remotely. With integrated ASPEED AST2400 graphics, dual Intel® I210-AT Gigabit Ethernet ports, and comprehensive expansion via multiple PCIe 3.0 x16 slots, the ASUS ESC4000 G3S is optimized for robust scalability, energy efficiency, and enterprise reliability.
| Category | Specification |
|---|---|
| System Type | Server Barebone |
| Form Factor | Rack-mountable – 2U |
| Server Scalability | 2-way |
| Chipset | Intel C612 |
| Processor Socket | LGA2011-v3 |
| Processor Support | Up to 2 Intel Xeon processors (E5-2600 v3/v4 family) |
| CPU Installed | None (supports upgrade) |
| Memory Type | DDR4 SDRAM (288-pin DIMM) |
| Memory Slots | 16 (total) / 16 (free) |
| Maximum Memory | Up to 1 TB LRDIMM |
| Memory Features | Quad-channel architecture, LRDIMM support |
| Storage Bays | 6 x hot-swap 2.5″ SATA bays |
| Drive Interface | SATA 6 Gb/s |
| RAID Support | RAID 0, 1, 5, 10 |
| Installed Storage | None |
| Optical Drive | None |
| Expansion Slots | 8 x PCIe 3.0 x16 (full-length, full-height) + 1 x PCIe 3.0 x24 (half-length, low-profile) |
| Graphics Controller | ASPEED AST2400 (32 MB video memory) |
| Video Output | VGA |
| Networking | 2 x Intel I210-AT Gigabit Ethernet + 1 x Management NIC (ASMB8-iKVM) |
| Network Features | KVM over IP support |
| Interfaces | 2 x USB 3.0, 2 x USB 2.0 (front), 1 x serial, 1 x VGA, 1 x management NIC |
| Power Supply | 2 x 1620 W redundant PSUs (80 PLUS Platinum, 1+1 redundancy) |
| Input Voltage | AC 120/230 V (50/60 Hz) |
| Cooling | Air duct with dual CPU heatsinks included |
| Remote Management | ASMB8-iKVM card (included) |
| Compliant Standards | BSMI, FCC |
| Dimensions (W × D × H) | 44.4 cm × 75 cm × 8.7 cm |
| Operating Temperature | 10 °C – 35 °C |
| Color | Black |
| Included Accessories | 2 × CPU Heatsinks, Air Duct, ASMB8-iKVM Remote Management Card |
