Description
The ASUS ESC4000A-E12-26WGPT is a high-performance 2U accelerator server engineered for demanding AI and HPC workloads. Powered by a single AMD EPYC™ 9004 or 9005 series processor with AMD 3D V-Cache™ technology, it delivers exceptional compute density with support for up to four dual-slot GPUs, enabling massive parallel processing and scalability for enterprise and research applications.
Designed with PCIe 5.0 readiness and comprehensive cooling flexibility, the ESC4000A-E12-26WGPT ensures efficient performance even under intensive computational loads. The system supports up to 3 TB of DDR5 memory across 12 DIMM slots and accommodates a versatile array of storage options, including six NVMe drives and multiple hot-swap bays.
With dual Gigabit LAN ports, optional OCP 3.0, and ASUS ASMB11-iKVM for remote management, this server offers advanced IT infrastructure control and reliability. Ideal for AI inferencing, virtualization, streaming, and cloud computing, the ESC4000A-E12-26WGPT combines power, expandability, and intelligent manageability in a compact 2U form factor.
| Category | Specification |
|---|---|
| Form Factor | 2U Rackmount Accelerator Server |
| Processor Support | 1 × Socket SP5 (LGA 6096) AMD EPYC™ 9004 / 9005 Series (up to 400 W TDP) with AMD 3D V-Cache™ technology |
| Memory | 12 × DIMM slots (12-channel per CPU) / Up to 3 TB DDR5 4800/4400 RDIMM or 3DS RDIMM |
| Expansion Slots | Up to 12 × PCIe Gen5 slots (4 × x16 for dual-slot GPUs or 8 × x16 for single-slot GPUs; 1 × x16 Gen5; 1 × x16/x8 Gen5 or OCP socket; 1 × x8 Gen5) |
| GPU Support | Up to 4 × dual-slot GPUs (NVIDIA NVLink®, BlueField DPU support) |
| Storage Bays | 2 × 2.5" & 4 × 3.5" Hot-swap Bays (SATA/SAS*/NVMe) — Configurable by SKU |
| RAID / HBA Options | ASUS PIKE II 3008 HBA (8-port SAS 12 Gb/s) / ASUS PIKE II 3108 RAID Card / Broadcom MegaRAID 9540-8i / 9560-16i |
| Networking | 2 × Gigabit LAN (Intel I350 Controller) + 1 × Management Port (RJ45) |
| Graphics | Aspeed AST2600 64 MB Onboard Controller |
| Front I/O Ports | 4 × USB 3.2 Gen1 Ports |
| Rear I/O Ports | 2 × USB 3.2 Gen1, 2 × RJ45 LAN, 1 × Management Port, 1 × VGA |
| Management | ASUS Control Center (Classic) / ASMB11-iKVM Remote Management |
| Cooling Options | Liquid Cooling and Enhanced Air Cooling Solutions |
| Power Supply | 1 + 1 Redundant 2600 W 80 PLUS Titanium CRPS-R Power Supply |
| Dimensions | 800 × 439.5 × 88.9 mm (2U); 845.45 mm Depth for Immersion Cooling |
| Weight | Net: 24 kg |
| Operating Environment | Operating Temp: 10 °C – 35 °C |
| Ideal For | AI Training / Inference • HPC • Virtualization • Cloud & Enterprise Applications |
