Description
The ASUS ESC8000 G3 is a high-performance 3U rackmount server built to power modern enterprise, HPC, and GPU computing workloads. Featuring dual LGA2011-v3 sockets with Intel® C612 chipset support, this scalable 2-way platform accommodates up to two Intel Xeon processors, 24 DIMM slots for up to 1.5 TB DDR4 ECC memory, and 8 PCIe 3.0 x16 expansion slots to deliver exceptional flexibility for GPU-intensive applications.
Engineered with a front-parallel airflow design and 80 PLUS Platinum-rated 1600W redundant power supplies, the ESC8000 G3 ensures optimal thermal efficiency and reliability in demanding datacenter environments. With integrated ASPEED AST2400 graphics, dual Intel Gigabit Ethernet ports, and ASWM Enterprise management software, it offers robust manageability and seamless scalability for mission-critical workloads.
| Category | Specification |
|---|---|
| Product Type | Rackmount Server Barebone |
| Form Factor | 3U Rack-mountable |
| Processor Support | Dual Socket LGA2011-v3 (Up to 2 CPUs, Intel Xeon) |
| Chipset | Intel® C612 |
| Memory Slots | 24 x DIMM 288-pin |
| Max Memory Capacity | Up to 1.5 TB DDR4 ECC (LRDIMM, RDIMM, NVDIMM) |
| Memory Type | DDR4 SDRAM, ECC, Registered |
| Drive Bays | 6 x Hot-Swap 2.5" SATA |
| Storage Interface | SATA 6Gb/s |
| RAID Support | RAID 0, 1, 5, 10 |
| Graphics | ASPEED AST2400 (32 MB Video Memory) |
| Networking | 2 x Intel I210-AT Gigabit Ethernet |
| Expansion Slots | 8 x PCIe 3.0 x16 (full-length, full-height) 1 x PCIe 3.0 x16 (x8 mode) 1 x PCIe 3.0 x8 (half-length) 1 x M.2 slot |
| USB Ports | 2 x USB 2.0 (front), 2 x USB 3.0 (front) |
| Video Output | 1 x VGA |
| Serial Port | 1 x Serial |
| Management Port | 1 x Dedicated |
| Included Accessories | 2 x CPU Heatsinks, Rack Rail Kit |
| Power Supply | 3 x 1600W Redundant (80 PLUS Platinum, N+1) |
| Power Input | AC 120/230 V, 47–63 Hz |
| Cooling | Front-parallel airflow design |
| Operating Temperature | 10°C to 35°C |
| Dimensions (W x H x D) | 44.7 x 13.06 x 75.9 cm |
| Weight | 29.2 kg |
| Color | Black |
| Compliance | FCC Class A, BSMI |
| Operating System | No OS pre-installed |
| System Management | ASUS ASWM Enterprise (Web-based) |
