Description
The ASUS ESC8000A-E11-4PS22M2 is a powerful 4U dual-socket GPU server engineered for demanding AI, deep learning, and HPC workloads. Built on the AMD EPYC™ 7003 platform with AMD 3D V-Cache™ technology, it delivers exceptional compute density and energy efficiency. The system supports up to 8 PCIe 4.0 dual-slot GPU cards, enabling parallel processing for large-scale AI models, cloud, or virtualized environments.
Designed with flexibility in mind, the ESC8000A-E11-4PS22M2 offers 11 PCIe Gen 4.0 slots, optional OCP 3.0 NIC socket, and up to 8 NVMe/SATA/SAS hot-swap storage bays. With ASUS Control Center and ASMB10-iKVM management, administrators gain full in-band and out-of-band control. The redundant 2 + 2 3000 W 80 PLUS Titanium/Platinum PSUs ensure continuous uptime in mission-critical deployments.
Ideal for enterprises, research institutions, and AI developers seeking scalable GPU performance and efficient data-center management.
| Category | Specification |
|---|---|
| Processor | 2 × Socket SP3 (LGA-4094), supports 3rd Gen AMD EPYC™ processors with AMD 3D V-Cache™ (up to 280 W TDP) |
| Form Factor | 4U Rack-mountable |
| Memory | 32 × DDR4-3200 RDIMM/LRDIMM slots (8 channels per CPU), up to 4 TB capacity |
| Expansion Slots | 11 × PCIe Gen 4.0 slots: 8 × x16 for dual-slot GPUs, 1 × x16 (OCP 3.0 NIC optional), 1 × x8 (low-profile), 1 × x16 (for RAID/HBA card) |
| GPU Support | Up to 8 × PCIe 4.0 dual-slot GPU cards |
| Storage Bays | 8 × 2.5"/3.5" hot-swap bays (up to 8 × NVMe with RAID card) |
| Networking | 1 × Dedicated management port (RJ-45 with BMC AST2600); optional OCP 3.0 NIC for LAN flexibility |
| Management | ASUS Control Center (in-band); ASMB10-iKVM (out-of-band) |
| Security | Optional TPM / PFR Module |
| Front I/O Ports | 2 × USB 3.2 Gen 1, 1 × VGA, optional COM port |
| Indicators & Buttons | Power button/LED, Location button/LED, Message LED, HDD Access LED, Q-Code/Port 80 LED |
| Dimensions (W × D × H) | 439 × 800 × 175.6 mm (17.28" × 31.5" × 6.9") |
| Weight | Net 39 kg; Gross 49 kg |
| Power Supply | 2 + 2 Redundant 2200 W (80 PLUS Platinum) / 3000 W (80 PLUS Titanium) PSUs |
| Operating Temperature | 10 °C – 35 °C operating; –40 °C – 70 °C storage; 20–90% non-condensing humidity |
| Supported OS | Refer to ASUS server support page for latest compatibility |
