Description
The ASUS ESC8000A-E12P-3W10G is a powerful 4U dual-socket server built for next-generation AI and HPC workloads. Powered by 4th Gen AMD EPYC™ 9004 Series processors with AMD 3D V-Cache technology, it supports up to eight dual-slot GPUs, NVIDIA NVLink® Bridge, and BlueField DPU for extreme performance scalability.
With PCIe 5.0 connectivity, DDR5 4800 MHz memory, and up to 3 TB RAM per CPU, the ESC8000A-E12P-3W10G delivers superior bandwidth and compute density for enterprise-grade AI training, virtualization, and data-center applications.
A redundant 80 PLUS Titanium power supply ensures stable energy efficiency, while advanced air and liquid-cooling solutions support sustained GPU performance in high-density environments. Integrated ASUS Control Center management, ASMB11-iKVM, and TPM 2.0 hardware security make it a reliable, scalable choice for modern AI infrastructure.
| Category | Specification |
|---|---|
| Processor Support | 2 × Socket SP5 (LGA 6096), AMD EPYC™ 9004 Series Processors with AMD 3D V-Cache Technology |
| Chipset / Core Logic | AMD EPYC™ 9004 Series |
| Memory Slots | 24 × DIMM (12 per CPU) DDR5 4800 / 4400 RDIMM / 3DS RDIMM |
| Maximum Memory | Up to 3 TB per CPU socket |
| Expansion Slots | 8 × PCIe 5.0 x16 for GPUs (FH, FL) · 4 × PCIe 5.0 x16 for NICs · 1 × PCIe 5.0 x16 for HBA/RAID (LP, HL) · 1 × OCP 3.0 Socket Option (x16) |
| Storage Bays | 8 × 3.5" Hot-Swap Front Bays (Support NVMe / SATA / SAS*) *SAS requires HBA/RAID card |
| Disk Controller Options | Broadcom MegaRAID 9560-16i / 9540-8i · ASUS PIKE II 3008 / 3108 |
| M.2 Slots | 1 × M.2 (Up to 22110, PCIe Gen 3 ×4) |
| Networking | 2 × 10 GbE LAN (RJ45, X710-AT2) or 2 × 1 GbE LAN (RJ45, I350-AM2) + 1 × Dedicated Management Port |
| Graphics Controller | ASPEED AST2600 64 MB |
| Front I/O Ports | 2 × USB 3.2 Gen 1 · 1 × VGA |
| Rear I/O Ports | 2 × LAN (10 GbE / 1 GbE) · 1 × Management Port · 1 × COM |
| Management | ASUS Control Center (Classic) · ASMB11-iKVM (KVM-over-IP) |
| Security | TPM 2.0 Support · Regular Firmware Updates for Vulnerability Protection |
| Cooling Solutions | Air / Liquid / Direct-to-Chip (D2C) / Immersion Cooling Options · Supports Liquid-Cooled NVIDIA A100 GPU |
| Power Supply | 2+2 Redundant 2600 W / 3000 W 80 PLUS Titanium Power Supply (220–240 Vac, 15.5 A ×4, 50–60 Hz) |
| Dimensions (W × D × H) | 440 × 800 × 174.5 mm (17.32" × 31.5" × 6.87") – 4U Rackmount |
| Net / Gross Weight | 27 kg / 52 kg (CPU, RAM, HDD excluded) |
| Operating Environment | 10 °C ~ 35 °C (Operating) · –40 °C ~ 70 °C (Storage) · 20–90 % RH (Non-Condensing) |
| Supported OS | Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu, VMware |
