Description
The ASUS ESC8000A-E13P-32W is a next-generation, high-performance 4U NVIDIA MGX™ server engineered for enterprise AI, HPC, and data center workloads. Powered by dual AMD EPYC™ 9005 series processors with up to 192 Zen 5/5c cores and supporting TDP up to 500W per socket, this platform delivers extraordinary computing density and scalability.
Compliant with the NVIDIA MGX™ architecture, it supports up to eight 600W dual-slot GPUs and NVIDIA NVLink™ 2-Way or 4-Way bridges for seamless GPU interconnects and superior data throughput. The modularized design and ASUS-exclusive toolless serviceability ensure easy deployment and over 90% faster maintenance, while the 3+1 redundant 3200W 80 PLUS Titanium power supply provides stable, energy-efficient operation.
Built for the future of AI infrastructure, the ESC8000A-E13P-32W accelerates large language model (LLM) inference, HPC simulations, and data center virtualization with unmatched reliability and flexibility.
| Category | Details |
|---|---|
| System Type | 4U Rackmount NVIDIA MGX™ Server |
| Processor Support | 2 × AMD EPYC™ 9005 Series (Socket SP5, up to 500W TDP each) |
| Architecture | NVIDIA MGX™ Modular Architecture |
| Memory Support | 24 × DDR5 RDIMM Slots (12-channel per CPU), up to 3TB DDR5 6400/5600 |
| GPU Support | Up to 8 × Dual-Slot GPUs (600W each), NVIDIA NVLink™ 2-Way or 4-Way Bridge Support |
| DPU/NIC Support | Up to 5 × PCIe 5.0 x16 slots for NICs or NVIDIA BlueField®-3 DPUs |
| Expansion Slots | 14 Total: 8 × PCIe Gen5 x16 (FHFL GPU), 5 × PCIe Gen5 x16 (FHHL NIC/DPU), 1 × PCIe Gen5 x8 (FHHL) |
| Storage Bays | 8 × 2.5” Front Hot-Swap Bays (Supports up to 8 NVMe) |
| M.2 Slots | 2 × M.2 (PCIe 5.0 x4, up to 22110) |
| Networking | 2 × 10GbE LAN (RJ45, Intel X710-AT2) + 1 × RJ45 Management Port |
| Graphics | ASPEED AST2600 64MB VGA |
| Front I/O Ports | 1 × Mini DisplayPort, 2 × USB 5Gbps, 1 × Debug Port |
| Rear I/O Ports | 1 × USB 5Gbps, 2 × RJ45 LAN, 1 × RJ45 Management LAN |
| Power Supply | 3+1 Redundant 3200W 80 PLUS Titanium PSU |
| Cooling System | 5 × GPU Fans + 5 × System Fans |
| Dimensions (W×D×H) | 439.5 × 800 × 175 mm (17.3” × 31.5” × 6.9”) |
| Net Weight | 42 kg |
| Operating Temperature | 10°C to 35°C |
| Management Software | ASUS Control Center Enterprise, ASMB12-iKVM (BMC AST2600) |
| Compliance | NVIDIA MGX™, RoHS |
| Target Applications | AI Training, LLM Inference, HPC, Data Center, Virtualization |
