Description
The Juniper Networks EX4100-F-24P is a secure, cloud-ready, AI-driven Ethernet switch purpose-built for modern enterprise campus, branch, and remote office environments. It combines the power of Mist AI™, Juniper Mist™ Wired Assurance, and Marvis Virtual Network Assistant to simplify operations, enhance visibility, and ensure a superior user and device experience.
With 24 x 1GbE PoE+ access ports, the EX4100-F-24P delivers up to 30W per port and a total PoE power budget of 370W, supporting a wide range of devices including IP phones, access points, and IoT endpoints. Its four 1GbE/10GbE SFP+ uplinks provide high-speed connectivity to the network core, while Virtual Chassis technology allows up to ten EX4100-F switches to operate as a single logical device—simplifying management and scalability.
Designed for high availability and AI-driven automation, the EX4100-F-24P supports EVPN-VXLAN, microsegmentation using group-based policy (GBP), and flow-based telemetry for proactive monitoring and anomaly detection. Managed via the Juniper Mist Cloud, it provides zero-touch provisioning (ZTP), automated troubleshooting, and ongoing performance optimization for wired networks.
Built on Junos® OS, the EX4100-F-24P delivers consistent, carrier-grade reliability, rich Layer 2/3 features, and modern management through Juniper Flex Licensing options—Standard, Advanced, and Premium tiers—to scale capabilities with your network’s needs.
| Feature | Specification |
|---|---|
| Model | EX4100-F-24P |
| Product Type | Managed Gigabit Ethernet Switch |
| Ports | 24 x 10/100/1000BASE-T PoE+ |
| Uplink Ports | 4 x 1GbE/10GbE SFP/SFP+ |
| Virtual Chassis Ports | 4 x 10GbE SFP+ (can serve as uplinks) |
| PoE Standard | IEEE 802.3af/at (PoE/PoE+) |
| PoE Power Budget | 370 W total, 30 W per port |
| Switching Capacity | 208 Gbps (bidirectional) |
| Forwarding Rate | 154 Mpps |
| Virtual Chassis Support | Up to 10 units |
| Processor | 1.7 GHz ARM CPU |
| Memory | 4 GB DRAM with ECC; 8 GB storage |
| Operating System | Junos® OS |
| AI Management | Juniper Mist Wired Assurance, Marvis Virtual Network Assistant |
| Fabric Support | EVPN-VXLAN, GBP (Group-Based Policy) |
| Telemetry | Flow-based telemetry and Junos Telemetry Interface (JTI) |
| High Availability | Graceful Routing Engine Switchover (GRES), Nonstop Bridging (NSB), Nonstop Routing (NSR) |
| Dimensions (W x H x D) | 17.36 x 1.72 x 12.26 in (44.09 x 4.37 x 31.14 cm) |
| Weight | 10.46 lb (4.75 kg) |
| Cooling | Front-to-back airflow (AFO) |
| Power Consumption (Max) | 80 W (input power, no PoE) |
| Operating Temperature | 32° to 113°F (0° to 45°C) |
| Management Interfaces | Console, USB, Ethernet (out-of-band), Web, SNMP, CLI |
| Compliance | IEEE 802.3af/at, 802.1X, 802.1Q, 802.3ad, LLDP, RSTP, MSTP |
| Warranty | Enhanced Limited Lifetime Warranty with lifetime software updates and next-day advance replacement |
