Description
The Vertiv Liebert EXS V-Model EXSV-30KN is a high-performance 30kVA/30kW three-phase tower UPS designed for critical IT applications. With true online double-conversion technology, it provides continuous and clean power to essential equipment such as servers, VoIP, storage devices, and medical systems. This compact and integrated UPS system includes a factory-installed Liebert Intellislot SNMP card, a 10-minute runtime at full load, and support for flexible UPS, PDU, and battery arrangements. It is ENERGY STAR® 2.0 certified, offers maintenance bypass, and comes with built-in network and environmental monitoring features for peace of mind in any data center or commercial environment.
| Category | Details |
|---|---|
| Brand | Vertiv Liebert |
| Model | EXSV-30KN |
| UPS Type | Online Double-Conversion |
| Form Factor | Tower |
| Power Capacity | 30kVA / 30kW |
| Input Voltage | 208/120VAC or 220/127VAC (3-Phase, 4-Wire) |
| Output Voltage | 208/120VAC or 220/127VAC |
| Power Factor | 1.0 (Unity) |
| Input Frequency | 40Hz – 70Hz |
| Output Frequency | 60Hz |
| Run Time (Full Load) | 10 minutes |
| Run Time (Half Load) | 26 minutes |
| Battery Type | Sealed Valve-Regulated Lead Acid |
| Battery Weight | 762.60 lbs |
| Communication | IS-Unity SNMP, Modbus RS-485, TCP, Relay Contact |
| Monitoring Sensors | Temperature, Humidity |
| Certifications | UL 1778, CSA 22.2 No.107.3, ENERGY STAR 2.0, RoHS, WEEE |
| Software | Vertiv™ Power Insight (Free Download) |
| Dimensions (HxWxD) | 78.7" x 23.6" x 39.3" |
| UPS Weight | 1521 lbs |
| Shipping Weight | 587 lbs (as listed) |
| Warranty | 1-Year Limited Warranty |
| Product Condition | New and Factory Fresh |
