Description
The Extreme Networks ExtremeSwitching X465-24XE-B3 is a high-performance, fiber-based enterprise switch engineered for demanding edge and aggregation environments requiring scalable 10Gb connectivity. Designed with 24 SFP+ ports supporting 1Gb and 10Gb Ethernet, this model delivers exceptional throughput, low latency, and wire-speed performance for modern data-driven networks.
Built on ExtremeXOS, the X465-24XE provides advanced Layer 2 and Layer 3 capabilities, enabling secure, resilient, and highly available network operations. With support for MACsec encryption, integrated application hosting, and Fabric Attach for automated network provisioning, the switch enhances both security and operational efficiency.
The included 350W AC power supply bundle ensures reliable deployment, while modular VIM uplink options offer flexibility for 10Gb, 25Gb, and 40Gb expansion. With high-density fiber connectivity, robust stacking capabilities, and cloud-based management via ExtremeCloud IQ, the X465-24XE-B3 is ideal for enterprise wiring closets, campus aggregation, and high-performance edge deployments.
| Specification | Details |
|---|---|
| Switch Model | X465-24XE |
| Form Factor | 1U Rack-Mountable |
| Ports | 24 x 1Gb/10Gb SFP+ Fiber Ports |
| Uplink Options | Modular via VIM slot (10Gb / 25Gb / 40Gb supported) |
| Stacking | Up to 8 switches, 160Gb stacking bandwidth (full duplex) |
| Switching Capacity | Up to 888 Gbps |
| Forwarding Rate | Up to 660.7 Mpps |
| MAC Address Table | Up to 272K entries |
| VLAN Support | Up to 4092 VLANs |
| Jumbo Frames | Up to 9216 bytes |
| Routing Capabilities | Advanced Layer 3 (IPv4/IPv6, multicast, policy-based routing) |
| Security Features | MACsec (128-bit and 256-bit AES), ACLs, role-based policy |
| Fabric Support | Fabric Attach for automated fabric connectivity |
| Application Hosting | Integrated Application Hosting support |
| Management | ExtremeCloud IQ, CLI, Web GUI |
| CPU & Memory | Dual-core x86 CPU, 8GB DRAM, 8GB eMMC |
| Power Supply | 1 x 350W AC PSU (included in B3 bundle) |
| Redundancy | Hot-swappable power supplies and fans |
| Cooling | Redundant fan modules |
| Operating Temperature | 0°C to 45°C |
| Dimensions | 1.70 in (H) x 17.34 in (W) x 19.23 in (D) |
| Weight | Approx. 7.77 kg (17.13 lb) |
| Compliance | RoHS, WEEE, global safety and EMC standards |
