Description
The Advantech UNO-3285G-674BE is a high-performance, fanless control cabinet PC engineered for demanding industrial automation and machine control environments. Powered by a 6th Generation Intel® Core™ i7-6822EQ processor, this system delivers reliable multi-core computing while maintaining silent, maintenance-free operation.
Designed for flexibility inside control cabinets, the UNO-3285G supports extensive expansion with dual PCIe x8 and PCI slots, dual hot-swappable storage bays with RAID 0/1 capability, and rich industrial I/O. Dual Gigabit Ethernet, multiple serial interfaces, and high-speed USB 3.0 ports ensure seamless connectivity to automation equipment, field devices, and industrial networks.
With dual redundant power inputs, wide operating temperature support, and rugged industrial certifications, the UNO-3285G-674BE is ideal for factory automation, machine vision, transportation systems, and mission-critical industrial computing applications.
| Specification | Details |
|---|---|
| Product Type | Fanless Control Cabinet Industrial PC |
| Processor | Intel® Core™ i7-6822EQ, Quad Core, 2.0 GHz |
| Chipset | Intel® QM170 |
| Memory | 8 GB DDR4 (Upgradeable up to 32 GB) |
| Storage | 1 × CFast slot, 1 × mSATA slot, 2 × 2.5" SATA bays (RAID 0/1 supported) |
| Expansion Slots | 2 × PCIe x8, 2 × PCI |
| Ethernet | 2 × Gigabit Ethernet (Intel i210-IT, Intel i219-LM) |
| USB Ports | 6 × USB 3.0 |
| Serial Ports | 2 × RS-232/422/485, 2 × RS-232 (pin header) |
| Display Outputs | 1 × DVI-I, 1 × HDMI |
| Power Input | Dual 12–36 VDC redundant power input |
| Power Consumption | 44 W typical, 120 W max |
| Operating Temperature | -20°C to 60°C (with airflow) |
| Storage Temperature | -40°C to 85°C |
| Mounting Options | Wall mount, stand mount, enclosure mount |
| Dimensions (W × D × H) | 182 × 238 × 177 mm |
| Weight | Approx. 4.5 kg |
| Operating System Support | Windows 7/8, Windows 10 LTSC, AdvLinux |
