Description
The HPE Networking Comware 5940 Switch (JH390A) is a high-performance, ultra-low-latency 1RU top-of-rack switch designed for modern data centers. Featuring 48 SFP+ 10GbE ports and 6 QSFP28 100GbE uplinks, it delivers up to 2.16 Tbps switching capacity and 1607 Mpps throughput—perfect for server access and aggregation in large enterprise and mid-sized networks.
Powered by HPE Comware v7 OS, it supports advanced Layer 2 and Layer 3 features including VXLAN, EVPN, and OpenFlow, along with Intelligent Resilient Fabric (IRF) for simplified management and high availability. Integrated with FlexFabric Network Analytics, this switch ensures real-time visibility and optimal network performance.
Whether deployed in a high-density data center or enterprise network core, the 5940 simplifies operations, enhances agility, and provides investment protection with no hidden license costs.
| Specification | Details |
|---|---|
| SKU / Model Number | JH390A |
| Product Type | Fixed-Port Top-of-Rack Data Center Switch |
| Ports | 48x 10G SFP+ |
| Switching Capacity | 2160 Gbps (2.16 Tbps) |
| Throughput | Up to 1607 Mpps |
| Latency | <1 µs at 10Gbps |
| Packet Buffer | 16 MB |
| Memory | 4 GB SDRAM |
| Stacking | IRF (up to 9 switches) |
| Management Interfaces | CLI, Telnet, FTP, SNMP, Out-of-Band, IMC |
| Power Supply | Dual hot-pluggable power supply and fan tray slots (PSU sold separately) |
| Power Input | 100–240 VAC or -40 to -60 VDC (varies by PSU) |
| Power Consumption | Max 196 W |
| Heat Dissipation | 887 BTU/hr (935.79 kJ/hr) |
| Dimensions (WxDxH) | 44 x 46 x 4.36 cm |
| Weight | 11 kg |
| Operating Humidity | 10% to 90% (non-condensing) |
| Software Features | Comware v7, VXLAN, EVPN, OpenFlow, ISSU, OVSDB, Network Analytics |
| Deployment Role | Server Access, Aggregation, Enterprise Core |
