Description
The Fluke Networks FQM-100-M Fiber QuickMap™ Kit is a high-performance multimode fiber distance and fault locator designed for fast, accurate troubleshooting without the complexity of a full OTDR. Operating at an 850 nm wavelength, it measures up to 4,921 feet (1,500 meters) of fiber in seconds, helping technicians locate severe bends, high-loss splices, breaks, and dirty connectors quickly.
Ideal for both installation and maintenance, the FQM-100-M detects live fiber signals before testing, identifies reflective and non-reflective incidents, and provides distance and power loss readings instantly. Its rugged construction, quick one-button operation, and six-second test time make it a powerful tool for reducing downtime and eliminating blind troubleshooting.
The kit includes a multimode fiber fault locator unit, UPC-UPC 2m patch cord, interchangeable SC adapter, carrying case, and AA batteries—ready for immediate deployment in the field.
| Feature | Specification |
|---|---|
| Fiber Type | Multimode 50/125 µm or 62.5/125 µm |
| Output Wavelength | 850 nm ± 10 nm |
| Dynamic Range | >11 dB |
| Max Distance | 1,500 m (4,921 ft) |
| Incident Detection | Up to 9 incidents |
| Distance Accuracy | ± (1 m + 0.1% x length) reflective / ± (3 m + 0.1% x length) non-reflective |
| Reflectance Accuracy | ± 4 dB |
| Loss Incident Detection | 0.70 dB default threshold (configurable 0.5–6.1 dB) |
| Live Fiber Detection | 600–1050 nm, +7 dB max input power |
| Test Time | < 6 seconds |
| Display | Backlit black & white LCD |
| Connectors | Removable/cleanable SC adapter (optional LC, ST, FT adapters) |
| Power | 2 × AA alkaline batteries (up to 1,500 tests) |
| Dimensions | 5.45" H × 12.25" L × 10.30" W |
| Environmental | 0°C to 50°C operating, -20°C to 60°C storage, 95% RH max |
| Compliance | EN 60825-2, EN 61326-1: 2004, CSA, FCC Part A Class A |
