Description
The Shure PA421BX is a professional-grade four-channel antenna combiner engineered to streamline RF management in complex in-ear monitoring setups. Designed for high-performance wireless environments, it allows up to four compatible PSM transmitters to share a single antenna, significantly reducing rack clutter while improving overall RF efficiency.
Operating in the 865–960 MHz frequency range, the PA421BX delivers stable, wideband performance ideal for touring, broadcast, and installed AV systems. Its advanced design minimizes intermodulation artifacts, ensuring a cleaner RF environment and more reliable signal transmission. Integrated DC power outputs simplify system cabling by powering connected transmitters directly, while LED indicators provide real-time monitoring of signal presence, overload conditions, and current draw.
With expansion capabilities for larger systems and an improved thermal design for quiet operation, the PA421BX is a dependable solution for professional audio engineers seeking scalable and efficient wireless system management.
| Specification | Details |
|---|---|
| Frequency Range | 865–960 MHz |
| RF Channels | Combines up to four transmitters |
| Impedance | 50 Ω |
| RF Input Connector | BNC (Active) |
| RF Output Connector | BNC |
| RF Gain | 0 dB (±2 dB) |
| Expansion Port | BNC (Passive), supports daisy-chaining |
| Expansion Port Insertion Loss | <4 dB |
| RF Expansion Port Range | 33 dBm (2 W) |
| DC Output Voltage | 15 V DC |
| DC Output Current (Per Output) | Up to 660 mA |
| DC Output Power (Per Output) | 9.9 W |
| LED Indicators | Signal presence, overload, current draw |
| Detection Threshold | 2.5 dBm (signal), 85 mA (current) |
| Overload Threshold | >24 dBm (RF), >660 mA (current) |
| Power Requirements | 100–240 V AC, 50–60 Hz |
| Power Consumption | 98 W maximum |
| Current Drain | 1.09 A at 100 V AC |
| Operating Temperature | −18°C to 63°C (0°F to 145°F) |
| Included Accessories | IEC power cord, DC power cables, BNC coaxial cables |
| Compatibility | Shure PSM Personal Monitor Systems |
