Description
The Brocade XBR-000255 4×16G FC QSFP+ Transceiver Module delivers reliable, high-bandwidth Fibre Channel connectivity across up to 2 km of single-mode fiber (SMF). Designed for Brocade Gen 5 Fibre Channel Directors such as the DCX 8510, it enables high-speed 4×16 Gbps aggregation for backbone inter-chassis links (ICLs).
This hot-pluggable QSFP+ module ensures maximum interoperability, power efficiency, and performance when paired with Brocade fabric switches. Ideal for enterprise storage networks demanding low latency and long-distance data transmission, the XBR-000255 supports Fibre Channel (FC) speeds up to 16 Gbps per channel while maintaining Brocade’s rigorous reliability and quality standards.
| Specification | Description |
|---|---|
| Manufacturer | Broadcom / Brocade® |
| Product Type | 4×16G Fibre Channel QSFP+ Transceiver |
| Model / Ordering P/N | XBR-000255 (1-pack) |
| Manufacturing Part Number | 57-1000310-01 |
| Data Rate | 4 × 16 Gbps FC (aggregate 64 Gbps) |
| Cable Type | Single-Mode Fiber (SMF) |
| Maximum Reach | 2 km |
| Connector Type | MPO / MTP |
| Wavelength | 1310 nm (typical) |
| Form Factor | QSFP+ (Hot-pluggable) |
| Supported Platforms | Brocade Gen 5 Directors (DCX 8510) and switches |
| Compatibility Notes | ICL only; not supported on FC32-64 module |
| Power Consumption | < 2 W (Typical) |
| Operating Temperature | 0 °C – 70 °C (Commercial) |
| Compliance | RoHS, Class 1 Laser Safety, FC-PI-5 Compliant |
| Package Options | 1-pack (XBR-000255) |
| Warranty | 1-Year Limited Warranty (Broadcom Standard) |
