Description
Ensure uninterrupted power for mission-critical devices with the Vertiv VA6N32A0 Rack Transfer Switch. This intelligent rPDU provides automatic source transfer in under 8 milliseconds, delivering redundant power to single-corded equipment without phase synchronization. With outlet-level monitoring, daisy-chain Ethernet connectivity, and optional environmental sensor support, it delivers superior visibility, control, and operational continuity. Ideal for high-availability edge and IT deployments.
| Attribute | Details |
|---|---|
| Part Number | VA6N32A0 |
| Power Rating | 30A, 120V, 2.8kW |
| Form Factor | 19" Horizontal Rackmount |
| Input Plugs | (2) NEMA L5-30P Twistlock |
| Outlets | (12) NEMA 5-20R |
| Breakers | (2) 20A Single Pole Magnetic (10kAIC) |
| Monitoring | Input, Outlet, and Circuit-level Monitoring |
| Environmental Monitoring | Yes, via optional remote sensors (up to 16) |
| Transfer Time | <4-8ms, auto-switching |
| Network Connectivity | Dual Ethernet (10/100/1000 Mbps), Daisy-chain up to 50 devices |
| Communication Protocols | SNMP v1/v2c/v3, HTTPS, SSH, RADIUS, Modbus TCP, more |
| Indicators | 12x LEDs, LCD touchscreen |
| Mounting | 2-Post and Adjustable 4-Post (24"–37") |
| Dimensions (HxWxD) | 3.39in x 17in x 18in (87mm x 432mm x 457mm) |
| Weight | 12 lbs (5.44 kg) |
| Finish | Black Powder Coat Steel |
| Warranty | 3 years standard, 5 years with registration |
| Certifications | UL 62368-1, c-UL, RoHS, FCC Part 15 Class A |
| Max Operating Temp | 60°C / 140°F |
