Description
The Vertiv VA5N31A0 PowerIT™ Rack Transfer Switch (RTS) ensures reliable, redundant power delivery to single-corded IT equipment. This intelligent horizontal 19" rackmount rPDU automatically switches power sources within 4–8 ms during outages—no phase sync required. It features switched unit-level monitoring, dual L6-30P inputs, six C13/C19 outlets, and optional environmental sensors for proactive infrastructure control. Daisy-chain up to 50 units via Ethernet and manage power remotely with advanced switching, sequencing, and monitoring capabilities.
| Attribute | Details |
|---|---|
| Model | VA5N31A0 |
| Product Type | Rack Transfer Switch (Switched, Unit Level Monitoring) |
| Input Voltage / Frequency | 200–240V / 50-60Hz |
| Current / Power Capacity | 30A / 4.9kW @ 208V |
| Transfer Time | < 4–8 milliseconds |
| Plug Type (Input) | (2) NEMA L6-30P |
| Receptacles | (6) Combination C13/C19 |
| Breakers | (2) 20A Double Pole Magnetic, 10kAIC Rated |
| Monitoring | Input, Circuit, Breaker, Environmental (optional) |
| Power Management | Individual Outlet Switching with Sequencing |
| Display | High Visibility LCD, LED Front & Rear |
| Network & Protocols | Dual Ethernet, SNMP, HTTP(S), SSH, Modbus TCP, etc. |
| Daisy-Chaining | Up to 50 devices on one IP address |
| Mounting | 19” Horizontal, Adjustable 4-Post (24”–37”), 2-Post Kit Included |
| Operating Temp | Up to 60°C (140°F) |
| Finish / Color | Black Powder-Coated Steel |
| Dimensions (HxWxD) | 1.72 x 17 x 18 in / 44 x 432 x 457 mm |
| Weight | 12 lbs / 5.44 kg |
| Warranty | 5 Years (with registration); otherwise 3 Years |
| Certifications | UL 62368-1, RoHS, FCC Part 15 Class A |
