Description
The Vertiv VP6N52A0 PowerIT™ Monitored rPDU provides reliable power distribution with outlet-level EC monitoring for critical IT equipment. With 12 combination C13/C19 outlets, 50A 208V DELTA input, and a 14.4kW load capacity, this 2U horizontal rack PDU delivers real-time power usage data via dual Ethernet ports. It supports environmental monitoring, remote access, and daisy-chaining up to 50 devices, ensuring uptime and operational insight. Ideal for data centers needing scalable, intelligent power management.
| Feature | Details |
|---|---|
| Model Number | VP6N52A0 |
| Form Factor | 2U Horizontal, 19in Rack Mount |
| Input Voltage / Type | 208V DELTA, 3-Phase |
| Input Current | 50A |
| Load Capacity | 14.4kW |
| Plug Type | 3P+E CA Twistlock |
| Outlets | 12 x Combination C13/C19 |
| Per Breaker / Phase | 2 per breaker, 4 per phase |
| Monitoring | Outlet Level EC Monitoring, Environmental Sensors |
| Display | Auto-Oriented LCD Touchscreen |
| Network Connectivity | Dual 10/100/1000Mbps Ethernet |
| Protocols Supported | SNMP (v1/v2c/v3), Modbus TCP, HTTPS, SSH, etc. |
| Daisy-Chaining | Up to 50 Devices |
| Power Cable | 10ft (3m), 6/4 Gauge, Left Rear Entry |
| Circuit Protection | (6) 20A Double Pole Magnetic Breakers |
| Material & Finish | Heavy Steel, Black Powder Coat |
| Certifications | UL 62368-1, RoHS, FCC Part 15 Class A |
| Country of Origin | USA (TAA & BAA Compliant) |
| Operating Temp. | Up to 60°C / 140°F |
| Warranty | 5-Year (with registration), otherwise 3-Year |
| Dimensions (HxWxD) | 3.39in x 17in x 12in (87mm x 432mm x 305mm) |
| Weight (Shipped) | 20 lbs (9.07 kg) |
