Description
The Vertiv VP6N62A1 PowerIT™ rPDU delivers reliable and intelligent power distribution with upgradeable outlet-level EC monitoring. This horizontal 2U rack PDU supports 60A 208V DELTA input and features 12 combination C13/C19 outlets. Designed for data centers and critical IT infrastructure, it offers real-time input and outlet monitoring, circuit/breaker tracking, and optional environmental sensing. With daisy-chain Ethernet, hot-swappable intelligence modules, and robust overcurrent protection, it helps optimize uptime, energy efficiency, and operational flexibility.
| Specification | Details |
|---|---|
| Model | VP6N62A1 |
| Form Factor | Horizontal, 2U |
| Input Voltage | 200–240V DELTA |
| Input Current | 60A, 3-Phase |
| Load Capacity | 17.2kW |
| Input Plug | IEC60309 3P+E, IP67 Rated |
| Power Cord Length | 10 ft / 3m |
| Outlet Type & Quantity | 12x Combination C13/C19 |
| Mounting | 19in Recess Mount |
| Monitoring Level | Input, Outlet, and Circuit/Breaker |
| Display | Auto-oriented LCD touchscreen |
| Network Connectivity | Dual Gigabit Ethernet, Daisy-chain (50 devices) |
| Supported Protocols | SNMP, HTTP(S), SSH, RADIUS, Modbus TCP, etc. |
| Environmental Monitoring | Optional (RJ45 jack supports up to 16 sensors) |
| Power Measurement Compliance | ANSI C12.1, IEC 62053-21 (1% Accuracy) |
| Protection | (6) 20A Double Pole Magnetic Breakers (10kAIC) |
| Build Finish | Heavy Steel, Black Powder Coat |
| Operating Temp. | Up to 60°C (140°F) |
| Certifications | UL 62368-1, RoHS, FCC Part 15 Class A |
| Warranty | 5 years (if registered within 120 days) |
| Country of Origin | USA (TAA and BAA COTS Compliant) |
| Weight | 20 lbs (9.07 kg) |
| Dimensions (HxWxD) | 3.39 x 17 x 12 in / 87 x 432 x 305 mm |
