Description
The Vertiv VP6N32A1 PowerIT™ Monitored rPDU offers reliable outlet-level power monitoring for your critical IT infrastructure. Designed for horizontal installation in standard racks, it features (24) combination C13/C19 outlets and a 10ft power cord with a L14-30P plug. With advanced environmental monitoring support, ANSI-compliant energy measurements, dual Ethernet ports, and daisy-chaining capabilities for up to 50 devices, this 30A, 208V unit ensures operational efficiency, fault tolerance, and network resilience in high-demand data center environments.
| Feature | Details |
|---|---|
| Part Number | VP6N32A1 |
| Form Factor | 2U, 19in Horizontal |
| Input Voltage | 208V |
| Input Current | 30A |
| Power Capacity | 5.7kW |
| Plug Type | NEMA L14-30P Twistlock |
| Receptacles | (24) Combination C13/C19 |
| Receptacle Voltage | 208V |
| Breaker Configuration | (2) 20A Double Pole Magnetic Breakers |
| Monitoring | Outlet-level, Circuit, and Input Monitoring |
| Display | Auto-orienting LCD touchscreen |
| Connectivity | Dual Ethernet (10/100/1000Mbps), USB, RS232 |
| Protocols Supported | SNMP, SSH, RADIUS, Modbus TCP, TACACS+, and more |
| Environmental Sensors | RJ connection supports up to 16 sensors |
| Indicators | 24 LEDs |
| Chassis Color | Black, Powder Coated Steel |
| Mounting | 19" Recess Mount |
| Dimensions (HxWxD) | 3.39in x 17in x 12in (87mm x 432mm x 305mm) |
| Weight | 18 lbs (8.16 kg) |
| Compliance | UL 62368-1, FCC Class A, RoHS, TAA, BAA |
| Warranty | 5 years (with registration), 3 years standard |
