Description
The Vertiv VP6N32A2 is a high-performance Monitored Outlet Level EC rPDU designed to deliver reliable power distribution with advanced monitoring and network capabilities. Supporting 30A at 120/208V WYE with an 8.6kW load capacity, this horizontal 2U unit features 24 combination C13/C19 outlets, remote environmental sensing, and daisy-chain Ethernet connectivity. Engineered for critical IT environments, it ensures uptime through fault tolerance and real-time energy usage insights with ANSI-compliant accuracy.
| Feature | Details |
|---|---|
| Model | VP6N32A2 |
| Form Factor | 2U Horizontal, 19 in / 483 mm |
| Power Capacity | 30A, 120/208V WYE, 8.6kW |
| Input Plug | NEMA L21-30P, 10ft / 3m cord |
| Outlets | 24 x Combination C13/C19 |
| Per Breaker/Phase Distribution | 8 outlets per 20A breaker |
| Circuit Protection | (3) 20A Double Pole Magnetic Breakers (10kAIC) |
| Monitoring | Input, Outlet, Circuit-level; kWh, W, VA, PF, V, A |
| Environmental Monitoring | Optional sensors (supports up to 16) via RJ sensor port |
| Display | Auto-orienting LCD touchscreen |
| Network Connectivity | Dual 10/100/1000 Mbps Ethernet ports |
| Protocols Supported | SNMP (v1/v2c/v3), Modbus TCP, RADIUS, DHCP, HTTP(S), SSH, Syslog, etc. |
| Data Access | JSON API, JSON/CSV datalogs |
| USB / Serial / IP Reset | Yes / RS232 via RJ45 / Yes |
| Build & Finish | Heavy Steel, Black Powder Coat |
| Operating Temp | Max 60°C (140°F) |
| Chassis Dimensions (HxWxD) | 3.39in x 17in x 12in / 87mm x 432mm x 305mm |
| Weight | 20 lbs (9.07 kg) |
| Certifications | UL & c-UL 62368-1, FCC Part 15 Class A, RoHS Compliant |
| Warranty | 5-year (with registration), 3-year standard |
| Compliance | TAA and BAA (COTS) compliant |
