Description
The Vertiv VP7N21A2 is a high-performance switched rack PDU (rPDU) that provides advanced outlet-level monitoring and remote switching capabilities for efficient power management. Designed for critical IT applications, this horizontal 19" rPDU supports 20A at 240/415V WYE input with a load capacity of 11.5kW. It features 12 combination C13/C19 outlets, robust environmental monitoring, daisy chain support for up to 40 units, and dual Ethernet ports for seamless integration. This unit offers compliance with ANSI C12.1 and IEC 62053-21 standards for precision and is ideal for mission-critical data center and IT infrastructure needs.
| Specification | Details |
|---|---|
| Model Number | VP7N21A2 |
| Input Voltage | 200-240/346-415V WYE |
| Input Current | 20A x 3 Phase |
| Power Capacity | 11.5kW |
| Receptacles | 12x Combination C13/C19 |
| Plug Type | IEC60309 3P+N+E, 20A, IP44 |
| Mounting | 19" Horizontal Rackmount |
| Monitoring | Input & Outlet Level (kWh, W, VA, PF, V, A), Circuit/Breaker Monitoring |
| Switching | Individual Outlet Switching with Sequencing |
| Network Connectivity | Dual Gigabit Ethernet, Daisy Chain Support (up to 40 rPDUs) |
| Protocols Supported | SNMP (v1/v2c/v3), HTTP/S, SSH, Modbus TCP, Syslog, TACACS+, RADIUS, etc. |
| Display | Auto-Oriented LCD Touchscreen + LED Indicators |
| Power Cable | 10 ft (3m), 12/5 AWG |
| Environmental Sensors Support | Yes, via optional remote sensors (up to 16 supported) |
| Operating Temp | Up to 60°C (140°F) |
| Chassis | Heavy Steel with Black Powder Coat Finish |
| Certifications | UL & c-UL 62368-1, FCC Class A, RoHS |
| Warranty | 5-year limited (with registration), 3-year standard |
| Dimensions (HxWxD) | 1.72 x 17 x 12 in (44 x 432 x 305 mm) |
| Weight | 10 lbs (4.54 kg) |
| Country of Origin | USA (TAA and BAA Compliant) |
