Description
The Vertiv VP7N62A0 PowerIT™ Switched rPDU delivers robust outlet-level power control and monitoring for critical IT infrastructure. With 12 combination C13/C19 outlets and a 60A 208V DELTA input, this horizontal 2U unit supports high-density power distribution in data centers. It features hot-swappable intelligence, circuit/breaker current monitoring, and optional environmental sensing. Dual Ethernet, USB, and serial connectivity ensure seamless integration, while compliance with ANSI/IEC standards guarantees accuracy. Designed with a durable black powder-coated steel chassis, the unit supports remote outlet switching, sequential power-up, and advanced daisy chaining of up to 40 rPDUs.
| Attribute | Specification |
|---|---|
| Model | VP7N62A0 |
| Form Factor | Horizontal, 2U, 19in Rack-Mount |
| Input Voltage | 200-240V Delta |
| Input Current | 60A, 3-Phase DELTA |
| Power Capacity | 17.2kW at 208V |
| Receptacles | 12 x Combination C13/C19 |
| Receptacle Voltage | 208V |
| Monitoring | Input & Outlet Level Monitoring, Breaker Monitoring |
| Switching | Individual Outlet Switching with Delay Options |
| Plug Type | IEC60309 3P+E, 60A, IP44 Splashproof |
| Power Cord Length | 10ft (3m), 6/4 Gauge |
| Network Interface | Dual Gigabit Ethernet (10/100/1000 Mbps) |
| Protocols Supported | SNMP v1/v2c/v3, SSH, HTTP/S, RADIUS, LDAP, TACACS+, etc. |
| Environmental Monitoring | Optional via 1 x RJ Sensor Port (Supports up to 16) |
| Indicators | 12 x LED Indicators, Local LCD Display |
| Chassis Color | Black Powder Coat |
| Operating Temp Max | 60°C (140°F) |
| Certifications | UL 62368-1, RoHS, FCC Part 15 Class A |
| Compliance | TAA & BAA COTS Compliant |
| Dimensions (HxWxD) | 3.39 x 17 x 12 in (87 x 432 x 305 mm) |
| Weight | 20 lbs (9.07 kg) |
| Warranty | 5 Years (with registration within 120 days) |
