Description
The Vertiv Liebert GXT5-3KL630RT2UXL is a high-performance, online double conversion UPS that delivers reliable, continuous power protection for mission-critical applications. With 3kVA/3kW capacity, this ENERGY STAR® certified UPS features a 2U rack/tower convertible form factor, a single-phase 208V input with L6-30P plug, and versatile output receptacles (L6-30R, L6-15R). The hot-swappable lead-acid batteries provide scalable runtime, supported by optional external battery cabinets.
Equipped with a gravity-sensing, color LCD screen, this unit simplifies operation and monitoring. Compatible with Vertiv’s RDU101 network card and Power Insight software, it offers centralized management for up to 100 UPS systems. Designed to meet environmental and electrical compliance standards (UL, RoHS, FCC, etc.), this unit includes a 3-year warranty with optional 2-year extension.
| Specification | Details |
|---|---|
| Brand | Vertiv Liebert |
| Model | GXT5-3KL630RT2UXL |
| Type | Online Double Conversion UPS |
| Form Factor | Rackmount/Tower Convertible (2U) |
| Input Voltage | 208V AC |
| Output Voltage | 200/208/220/230/240V AC |
| Input Plug | NEMA L6-30P |
| Output Receptacles | 2x NEMA L6-30R, 2x NEMA L6-15R |
| Power Capacity | 3kVA / 3kW |
| Power Factor | 1.0 |
| LCD Display | Full-Color Graphic LCD (Gravity Sensing) |
| Battery Type | Valve-regulated, Lead Acid (Hot Swappable) |
| Runtime (Full/Half Load) | 3 mins / 9 mins |
| Runtime w/ External Battery | 17 mins / 43.5 mins |
| Optional Accessories | External Battery Cabinet, RDU101 NIC Card |
| Communications | USB, Serial, RJ-45 Network Port |
| Certifications | ENERGY STAR 2.0, UL1778, FCC Class A, RoHS, REACH |
| Software Compatibility | Vertiv Power Insight |
| Environmental Sensors | Leak, Temperature, Humidity |
| Included Accessories | 4-Post Rail Kit, Tower Stand, USB Cable, Manual, Quick Start Guide |
| Dimensions (HxWxD) | 3.3" x 16.9" x 21.3" |
| Weight | 65.1 lbs |
| Shipping Weight | 81 lbs |
| Warranty | 3-Year Limited (Optional 2-Year Extension Available) |
