Description
The Hanwha Wisenet TEU-F16 is a 16-channel Ethernet-over-UTP extender designed to extend 10/100Mbps Ethernet and Pass-Through PoE over long-distance copper cabling. Built for large-scale surveillance and networking environments, this rack-mountable unit delivers reliable data and power transmission for remote IP cameras and network devices.
Supporting up to sixteen UTP channels with flexible 10/100Mbps switching and wire-pair configuration options, the TEU-F16 ensures stable operation even in demanding installations. It operates on local DC power and includes DIP switches for configuring data rate and wire-pair mode. With a compact 1RU design and robust build quality, it integrates easily into structured network racks, making it ideal for enterprise-grade CCTV systems, industrial networks, and multi-camera deployments.
| Category | Specification |
|---|---|
| Model | TEU-F16 |
| Channels | 16-channel Ethernet-over-UTP |
| Transmission Type | 10/100Mbps Ethernet extension |
| PoE Support | Pass-Through PoE (up to 15W) |
| Media | Twisted Pair UTP cable |
| Wire Pair Options | 1-pair or 4-pair (switch selectable) |
| DIP Switch Settings | Data rate (10/100Mbps), Wire pair selection |
| Extended Link Max Distance | Up to 3,000 ft depending on mode and power configuration |
| Power Input | 9 to 15 VDC |
| Power Consumption | 20W |
| Mounting | 1RU rack-mount chassis |
| Indicators | Power, Ethernet Link, Ethernet Activity, Extended Link |
| Use Case | Long-distance IP camera and network device extension |
| Compatibility | IEEE 802.3af PD devices (for PoE pass-through) |
| Environmental Requirements | Install in dry locations, protected from extreme temperature & humidity |
