Description
The SmartAVI HDR-UHD-32X32-S is a high-performance 32x32 HDMI matrix switch engineered for demanding AV environments that require seamless switching, ultra-high-definition video distribution, and flexible control. Designed for enterprise, control rooms, digital signage, and large-scale display systems, this solution supports up to 32 HDMI sources and 32 displays with full UHD 4K resolution at 60Hz.
With an integrated scaler and converter, the system ensures consistent output across all displays by automatically adjusting resolutions, delivering smooth and synchronized visuals. Seamless switching eliminates latency and signal disruption, making it ideal for mission-critical applications.
The HDR-UHD-32X32-S offers multiple control options including TCP/IP, RS-232, and front panel controls, along with intuitive management software that allows users to create and customize video wall layouts with ease. Its plug-and-play architecture ensures quick deployment without complex setup, while its robust hardware design guarantees reliability in continuous operation environments.
| Specification | Details |
|---|---|
| Video Resolution Support | Up to 3840 × 2160 @ 60Hz (4K UHD), 1080p @ 60Hz |
| HDMI Standard | HDMI 2.0, HDCP 2.2 compliant |
| Matrix Configuration | 32 Inputs × 32 Outputs |
| Video Bandwidth | 18 Gbps |
| Switching Type | Seamless switching |
| Scaling | Integrated scaler with resolution conversion to UHD |
| Input Interfaces | 32 × HDMI Type A (19-pin female) |
| Output Interfaces | 32 × HDMI Type A (19-pin female) |
| Audio Support | Stereo audio via HDMI and 3.5mm outputs |
| Audio Outputs | 32 × 3.5mm stereo (female) |
| Control Methods | Front panel, RS-232, TCP/IP (LAN), Web GUI |
| Software | HDR-UHD Manager (custom layout and video wall control) |
| Layout Options | Unlimited customizable display configurations |
| Operating Temperature | 0°C to 40°C |
| Storage Humidity | 20% to 90% |
| Power Supply | 110–240V AC, 50/60Hz |
| Power Consumption | 100W |
| Dimensions | 17" W × 7.125" H × 15" D |
| Weight | 24.45 lbs |
| Installation Type | Rackmount, plug-and-play ready |
