Description
The SmartAVI HDR-UHD-64X64-S is a high-performance 64x64 Ultra HD video wall processor and matrix switch engineered for large-scale AV environments that demand flexibility, reliability, and exceptional visual clarity. Supporting full 4K UHD resolutions at 60Hz, this all-in-one solution seamlessly manages up to 64 HDMI inputs and 64 outputs, enabling dynamic content distribution across expansive video walls.
Built with an integrated scaler and converter, the system ensures consistent output quality regardless of source resolution. Its seamless switching capability eliminates visual interruptions, making it ideal for mission-critical environments such as control rooms, command centers, corporate lobbies, and digital signage installations.
Designed for ease of use, the HDR-UHD-64X64-S offers multiple control options including front panel, RS-232, and TCP/IP, along with intuitive software that allows users to create and manage custom video wall layouts effortlessly. With plug-and-play deployment and virtually unlimited configuration possibilities, this solution delivers unmatched scalability and control for professional AV applications.
| Specification | Details |
|---|---|
| Video Resolution Support | Up to 3840 × 2160 @ 60Hz (4K UHD), 1080p @ 60Hz |
| Input Ports | 64 × HDMI 2.0 |
| Output Ports | 64 × HDMI |
| Video Bandwidth | 18 Gbps |
| HDCP Compliance | HDCP 2.2 |
| Video Switching | Seamless switching with no latency |
| Scaling | Integrated scaler for resolution conversion to UHD |
| Audio Support | Stereo audio via 3.5mm (64 inputs / 64 outputs) |
| Control Methods | Front panel, RS-232 (DB9), TCP/IP (RJ-45) |
| Software Control | Windows-based video wall management software |
| Configuration Modes | Video wall, quad view, individual display, custom layouts |
| Operating Temperature | 0°C to +40°C |
| Storage Humidity | 20% to 90% |
| Power Supply | 110–240V AC, 50/60Hz |
| Power Consumption | 100W |
| Dimensions | 19” W × 14” H × 28” D |
| Weight | 97 lbs |
| Installation Type | Rackmount |
| Use Cases | Control rooms, digital signage, retail, airports, corporate environments |
