Description
The ASUS RS720-E8-RS24-E is a high-density 2U rack server engineered for enterprise performance, scalability, and reliability. Featuring dual-socket Intel® Xeon® E5-2600 v3/v4 processor support on the Intel® C612 chipset, it delivers excellent computing power for data-intensive and virtualization workloads. Designed with 26 hot-swap 2.5" bays and up to 1024 GB DDR4 memory capacity, this server provides exceptional storage flexibility and expandability.
The RS720-E8-RS24-E integrates redundant 770W 80 PLUS Gold power supplies for uninterrupted uptime, and ASPEED AST2400 remote management for robust system monitoring and control. With four Gigabit Ethernet ports and comprehensive I/O including multiple PCIe 3.0 slots, it ensures optimal connectivity and expansion options for demanding enterprise environments.
Ideal for data centers, virtualization, and cloud deployments, the RS720-E8-RS24-E is built to deliver enterprise-grade performance, energy efficiency, and system stability.
| Category | Specification |
|---|---|
| Product Type | Rack Server |
| Form Factor | 2U Rack-Mountable |
| Processor Support | Dual Socket (2-way) |
| Processor Socket | LGA2011-v3 |
| Chipset | Intel C612 |
| CPU Included | None |
| Memory Type | DDR4 SDRAM |
| Memory Slots | 16 x DIMM 288-pin |
| Maximum Memory Supported | Up to 1024 GB (LRDIMM) |
| Storage Bays | 26 x Hot-swap 2.5" Bays |
| Drive Interface | SATA 6Gb/s |
| RAID Support | RAID 0, 1, 5, 10 |
| Graphics Controller | ASPEED AST2400 with 32 MB VRAM |
| Video Output | 1 x VGA |
| Networking | 4 x Gigabit Ethernet (Intel I350-AM2 & I350-BT2) |
| I/O Interfaces | 2 x USB 2.0, 2 x USB 3.0, 1 x PS/2, 1 x VGA, 1 x Mgmt Port |
| Expansion Slots | 3 x PCIe 3.0 x16 (LP), 2 x PCIe 3.0 x8 (LP), 1 x ASUS PIKE, 1 x M.2 |
| Power Supply | 2 x 770W 80 PLUS Gold Redundant PSU (1+1) |
| Cooling | Front-access fans with air duct |
| Dimensions (W x D x H) | 44.4 x 61.5 x 8.8 cm |
| Weight | 23 kg |
| Operating Temperature | 10°C – 35°C |
| Compliant Standards | FCC Class A, BSMI, C-Tick Certified |
| Included Accessories | Rack Rail Kit, Air Duct |
| Operating System | None (User-Installed) |
| Color | Black |
| Product Code / SKU | RS720-E8-RS24-E |
