Description
High-Performance Access for the Digital Workplace
The HPE Aruba Networking 2930F 48G PoE+ 4SFP+ Switch is designed for enterprises, SMBs, and branch offices seeking scalable, high-performance Layer 3 access. Featuring 48 PoE+ Gigabit ports and 4 SFP+ uplinks, it delivers up to 740W of PoE power—perfect for access points, IP phones, and security cameras.
Backed by Aruba's ClearPass Policy Manager, AirWave, and Central, this switch enables centralized security, performance monitoring, and zero-touch provisioning. With Virtual Switching Framework (VSF) for up to 8-member stacking, Access OSPF, RIP routing, and OpenFlow 1.0/1.3, it ensures future-ready, agile deployments with no additional software licenses required.
Whether you’re supporting a smart campus, cloud applications, or IoT, the 2930F simplifies wired access without compromising speed, visibility, or power efficiency.
| Specification | Details |
|---|---|
| Model Number | JL558A#AC3 |
| Ports | 48 x 10/100/1000 PoE+ (RJ-45), 4 x 1/10GbE SFP+ |
| Layer | Layer 3 |
| Management | Fully managed, AirWave, Aruba Central, Web, CLI, SNMP, Telnet |
| PoE Budget | Up to 740W PoE+ |
| Switching Capacity | 176 Gbps |
| Throughput | Up to 112 Mpps |
| Latency | <3.8 µs @ 1Gbps, <1.6 µs @ 10Gbps |
| Stacking | Up to 8 members with Virtual Switching Framework (VSF) |
| Memory | 1 GB DDR3 SDRAM, 4 GB eMMC, 12.38 MB packet buffer |
| Processor | Dual Core ARM Cortex A9 @ 1016 MHz |
| Power Supply | Internal |
| Power Consumption (Max) | 980W |
| Heat Dissipation | 420.9 BTU/hr |
| Mounting | Rack-mountable |
| Security Features | 802.1X, MAC/Web Authentication, Port Security, RADIUS/TACACS+, ACLs |
| QoS Features | Robust QoS with traffic prioritization and rate-limiting |
| Monitoring Tools | RMON, sFlow |
| Out-of-band Management | RS-232C serial or micro USB |
