Description
The HPE 32GB microSD RAID 1 USB Boot Drive is a turnkey, enterprise-class boot solution designed to provide resilient operating system mirroring through hardware RAID 1. Supporting popular virtualized environments such as VMware®, Linux®, and Windows®, this plug-and-play solution enables OS and data segregation, improving uptime and simplifying server configurations.
Ideal for HPE ProLiant DL325, DL345, DL365, DL380, ML30 Gen10, and Synergy 480 Gen10 platforms, it features dual 32GB microSD cards integrated with a RAID 1 controller for high endurance and reliable performance.
| Specification | Details |
|---|---|
| SKU | P21868-B21 |
| Form Factor | microSD USB |
| Total Usable Capacity | 32 GB |
| RAID Level | Preconfigured Hardware RAID 1 |
| Supported OS | VMware®, Linux®, Windows® |
| Performance | ≥28 MB/s Read, ≥29 MB/s Write |
| Class | UHS-I |
| Voltage Range | 4.0V (min) – 6.0V (max) |
| Interface Compliance | USB 2.0 |
| Dimensions (WxDxH) | 0.79 x 2.48 x 0.37 in (20.1 x 63 x 9.4 mm) |
| Weight | 0.882 lb (0.4 kg) |
| Compatibility | HPE ProLiant DL325/345/365/380 Gen10, ML30 Gen10, Synergy 480 Gen10 |
| Installation Type | Hot-plug, no PCIe slot, cables, or backplanes required |
| Use Case | OS mirroring and separation from data storage in virtualized environments |
| Boot Type | Flash (boot) |
