Description
The HPE Aruba Networking CX 8360-24XF2C v2 is a high-performance Layer 3 managed switch purpose-built for enterprise campus cores and dynamic data centers. Offering 24 SFP/SFP+ ports and 2 QSFP+/QSFP28 uplinks in a compact 1U design, it delivers up to 880 Gbps switching fabric and supports next-gen technologies such as MACsec, VSX, and the Network Analytics Engine (NAE). Ideal for secure, scalable, and intelligent network deployments, this model features front-to-back airflow, redundant power and fan support, and HPE Aruba’s AOS-CX modular OS for continuous availability and automation.
| Specification | Details |
|---|---|
| Model Number | JL710C#ABA |
| Product Series | HPE Aruba Networking CX 8360 v2 Series |
| Form Factor | Rack-mountable, 1U |
| Ports | 24x 1G/10G SFP/SFP+ ports2x 40G/100G QSFP+/QSFP28 uplink ports |
| Airflow | Front-to-back airflow |
| Switching Capacity | 880 Gbps |
| CPU | 1.8 GHz, 4-core, 64-bit |
| RAM | 16 GB |
| Flash/Storage | 32 GB |
| Packet Buffer | 32 MB |
| Routing Protocols | Static, RIP/RIPng, OSPF/OSPFv3, BGP-4, MP-BGP, PBR, ECMP, GRE, MPLS |
| Management Ports | RJ45 serial & USB-C console, RJ45 Mgmt, USB-A |
| Power Supplies | Dual hot-swappable, field-replaceable AC PSUs (included) |
| Power Consumption | Max: 325WIdle: 120W |
| Heat Dissipation | 1,280 BTU/hr |
| Dimensions (W x D x H) | 17.4 x 16.0 x 1.73 in (44.2 x 40.6 x 4.4 cm) |
| Weight | 17.80 lb (8.07 kg) |
| Software Features | HPE AOS-CX, NAE, VSX, REST APIs, Python automation |
