Description
The HPE Aruba Networking CX 8360-48Y6C v2 is a high-performance Layer 3 managed switch designed for modern enterprise campus cores and data centers. With 48 ports of 1/10/25G SFP/SFP+/SFP28 and 6 high-speed 40/100G QSFP+/QSFP28 uplink ports—including MACsec encryption on select ports—this 1U switch delivers up to 4.8 Tbps of switching capacity. It features front-to-back airflow, redundant hot-swappable fans and power supplies, and integrates HPE’s AOS-CX operating system with Network Analytics Engine (NAE) for deep visibility, telemetry, and automation.
The switch supports HPE VSX for high availability, REST APIs and Python scripting for automation, and a modular cloud-native OS architecture for microservices-driven resiliency. Ideal for transitioning from legacy 1/10G to 25G and 100G networks, it offers advanced capabilities such as dynamic segmentation, MACsec, and support for HPE Smart Rate multigigabit connectivity.
| Category | Details |
|---|---|
| Model Number | JL704C#ABB |
| Product Series | HPE Aruba Networking CX 8360 v2 Series |
| Form Factor | 1U rack-mountable |
| Airflow Direction | Front-to-back airflow |
| Switching Capacity | 4.8 Tbps |
| Forwarding Rate | 2,678 Mpps |
| Ports | 44 x 1/10/25G SFP/SFP+/SFP284 x 10/25G SFP+/SFP28 with MACsec4 x 40/100G QSFP+/QSFP282 x 40/100G QSFP+/QSFP28 with MACsec |
| Processor | 1.8 GHz 4-core 64-bit |
| Memory | 16 GB RAM |
| Flash Storage | 32 GB |
| Packet Buffer | 32 MB |
| Routing Protocols | Static, RIP v2, RIPng, OSPF, OSPFv3, BGP-4, MP-BGP IPv6, PBR, ECMP, GRE, MPLS |
| Management Ports | RJ45 Serial, USB-C Console, RJ45 Ethernet, USB-A |
| Power Supply | Dual hot-swappable AC power supplies (7.1A at 100-127V, 3.4A at 200-240V) |
| Power Consumption | Max: 725WIdle: 230W |
| Heat Dissipation | 1,450 BTU/hr |
| Dimensions (WxDxH) | 17.4 x 22.0 x 1.73 in (44.2 x 55.9 x 4.4 cm) |
| Operating System | HPE Aruba Networking AOS-CX |
| Analytics Engine | Integrated Network Analytics Engine (NAE) |
| High Availability | VSX, Dual Control Planes, Microservices Architecture |
| Automation Support | REST APIs, Python Scripting, HPE Fabric Composer |
