Description
The HPE Aruba Networking 9004 (JP) LTE TAA Branch Gateway delivers enterprise-class SD-WAN, networking, and security in a compact, fanless desktop form factor. Designed for branch offices and small campuses, this model supports up to 2,000 clients, integrates LTE Category 12 for WAN redundancy or primary uplink, and includes 4 Gigabit Ethernet ports.
It is part of Aruba’s 9000 Series SD-Branch solution, which unifies WLAN, LAN, WAN, and security, and is managed via Aruba Central. With up to 4 Gbps of firewall throughput, Dynamic Segmentation, and AI-powered analytics, it ensures secure, high-performance connectivity for distributed enterprises.
This TAA-compliant Japan (JP) variant is ideal for government and regulated environments requiring LTE failover or mobile connectivity.
| Specification | Details |
|---|---|
| SKU | R3V94A |
| Model | Aruba 9004 (JP) LTE TAA Branch Gateway |
| Ports | 4x 10/100/1000BASE-T (RJ-45) |
| LTE Module | Integrated LTE Cat 12 with dual SMA antenna connectors |
| Max Clients | 2,000 |
| Max Access Points | 128 (32 when used as mobility controller) |
| Firewall Throughput | 4 Gbps |
| Encrypted Throughput (AES-CBC) | 4 Gbps |
| Encrypted Throughput (AES-GCM) | 4 Gbps |
| Max Sessions (Firewall) | 128,000 |
| USB Ports | 1x USB 3.0 Type-A |
| Console Port | 1x Micro-USB, 1x RJ45 |
| LED Indicators | System, WAN, LAN, LTE, Central Status |
| Mounting | Desktop (fanless); optional rack tray |
| Power Input | 12V DC, 2.5A (AC-to-DC adapter included) |
| Power Consumption | Max 25W (with USB) |
| Dimensions (H x W x D) | 3.82 x 19.85 x 15.31 cm (1.5 x 7.815 x 6.03 in) |
| Weight | 1.24 kg (2.73 lbs) |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Humidity (Operating/Storage) | 10–90% / 10–95% (non-condensing) |
| Certifications | FCC/ISED, RED Directive 2014/53/EU, MIC, ANATEL, CCC, TAA |
| Software Support | ArubaOS 10.4+, Aruba Central (SD-WAN & UCC support) |
| Cluster Size | Up to 4 (Max 8K clients per cluster) |
