Description
The HPE Aruba Networking AP‑555 (EG) delivers ultra-high-performance Wi-Fi 6 (802.11ax) for demanding, high-density indoor environments such as enterprise campuses, lecture halls, and auditoriums. With dual radio 8x8/4x4 MIMO and an optional tri-radio mode, this access point supports a combined maximum data rate of up to 5.37 Gbps.
Optimized for efficient multi-user connectivity using technologies like OFDMA, MU-MIMO, and Target Wake Time (TWT), the AP-555 ensures seamless performance and power efficiency. Integrated Bluetooth 5, Zigbee, and USB support make it IoT-ready, while advanced security features including WPA3, Enhanced Open, and Trusted Platform Module (TPM) provide robust protection for enterprise networks.
| Attribute | Details |
|---|---|
| Part Number | JZ363A |
| Wi-Fi Standard | Wi-Fi 6 (802.11ax) |
| Radios | Dual-radio 8x8/4x4 MIMO; Optional tri-radio mode (2x 5GHz + 1x 2.4GHz) |
| Max Data Rate | Up to 5.37 Gbps (combined) |
| Antenna Type | Integrated omni-directional antennas (internal) |
| Peak Antenna Gain | 2.4 GHz: 4.3 dBi, 5 GHz: 5.8 dBi, Tri-radio 5 GHz: 5.5/5.6 dBi |
| ClientMatch | Yes (for optimal client association) |
| Ports | 2x HPE Smart Rate RJ-45 (1/2.5/5Gbps), 1x USB 2.0, 1x Console (Micro-B) |
| IoT Support | Integrated Bluetooth 5, Zigbee (802.15.4), USB expansion |
| Security | WPA3, Enhanced Open, PEF, TPM, Dynamic Segmentation |
| Mounting Options | Ceiling mount with pre-installed bracket (kit sold separately) |
| Power Consumption | Max: 38.2W (PoE), 32.6W (DC); Idle: 15W; Deep sleep: ~3.8W |
| Power Options | DC Power, 802.3bt PoE, Dual 802.3at PoE |
| Dimensions (HxWxD) | 58 x 260 x 260 mm |
| Weight | 1.57 kg |
| Certifications | UL2043, Wi-Fi CERTIFIED 6, WPA3, CE, FCC, RED, TAA Compliant (Egypt Only) |
| Warranty | Limited Lifetime Warranty |
