Description
The HPE Aruba Networking AP-567EX (EG) is a ruggedized outdoor access point purpose-built for hazardous locations requiring Class 1 Division 2 and ATEX Zone 2 compliance. Delivering up to 1.49 Gbps aggregate throughput with dual radio 2x2 MIMO Wi-Fi 6 capability, this AP provides fast, secure, and reliable wireless connectivity for environments such as oil fields, mining facilities, and industrial areas.
With integrated Bluetooth 5 and Zigbee radios, the AP-567EX supports IoT applications without additional network overlays. It includes advanced RF optimization, Dynamic Segmentation, and enhanced security features like WPA3, TPM, and policy enforcement firewalls (PEF). The device is engineered to endure extreme temperatures, moisture, and airborne contaminants, making it ideal for harsh outdoor deployments.
Mounting kits are sold separately. Includes Ethernet gland, grounding lug, and USB to USB-C console cable.
| Specification | Details |
|---|---|
| Model Number | R4W64A |
| Form Factor | Outdoor, Rugged, Hazardous Location Certified |
| Wi-Fi Standard | Wi-Fi 6 (802.11ax) |
| Radios | Dual Radio 2x2 MIMO (2.4GHz & 5GHz) |
| Max Data Rate | Up to 1.49 Gbps aggregate |
| IoT Support | Integrated Bluetooth 5 and 802.15.4 (Zigbee) |
| Certifications | Class 1 Division 2, ATEX Zone 2, CB, cTUVus, UL2043, CE, RED, Wi-Fi Alliance |
| Security | WPA3, Enhanced Open, PEF, TPM encryption and key protection |
| Operating Temperature | -40°C to +65°C |
| Power Consumption | Max 15.6W; Idle 4.2W; Deep sleep 1.7W |
| Power Supply | 48V DC PoE (802.3at/bt), Power supply sold separately |
| Network Interface | 1x RJ45 10/100/1000BASE-T, PoE+, USB-C console, reset button |
| Mounting | Optional mounting kits available |
| Antenna Gain | 5GHz: 6.7 dBi; 2.4GHz: 7.0 dBi; BLE/Zigbee: 3.0 dBi |
| Client Support | Up to 256 associated clients per radio |
| BSSIDs | Up to 16 per radio |
| Dimensions (W x D x H) | 16 x 16 x 12.1 cm |
| Weight | 1.09 kg |
| Warranty | Limited Lifetime Warranty |
