Description
The HPE Aruba Networking AP-675 (US) is a ruggedized tri-radio Wi-Fi 6E access point built for reliable outdoor wireless connectivity in harsh environments. Featuring internal omni-directional antennas, Bluetooth, Zigbee, and support for the full 2.4 GHz, 5 GHz, and 6 GHz spectrum, the AP-675 enables high-performance wireless networking for IoT and enterprise users alike. Ideal for industrial and campus deployments, it offers up to 3.9 Gbps aggregate throughput, operates with OFDMA, MU-MIMO, and comes equipped with embedded GPS, advanced security features, and smart power management via 2.5 GbE PoE and 1 GbE SFP uplinks.
Key Features
-
Tri-radio concurrent operation on 2.4GHz, 5GHz, and 6GHz bands
-
Wi-Fi CERTIFIED 6E™ for ultra-fast, low-latency performance
-
Integrated high-power Bluetooth and Zigbee radios
-
Supports up to 3.9 Gbps maximum data rate
-
Built-in omnidirectional internal antennas
-
Embedded GPS for self-location
-
Intelligent Power Monitoring (IPM) and dynamic power saving
-
Supports Dynamic Segmentation, WPA3, Enhanced Open, and TPM
-
Outdoor-rated, rugged design with extended temperature range
-
2.5 GbE PoE+ and 1 GbE SFP ports
| Specification | Details |
|---|---|
| Model Number | S0P50A (AP-675 US) |
| Product Type | Outdoor Wireless Access Point |
| Wi-Fi Standard | Wi-Fi 6E (IEEE 802.11ax) |
| Radios | Tri-radio (2.4 GHz, 5 GHz, 6 GHz concurrent) |
| MIMO | 2x2:2 MIMO per radio |
| Max Aggregate Data Rate | Up to 3.9 Gbps |
| Internal Antennas | 2.4 GHz: 3.8 dBi; 5 GHz: 5.7 dBi; 6 GHz: 5.9 dBi |
| Bluetooth/Zigbee Antenna | Integrated, omnidirectional, peak gain of 4.5 dBi |
| Client Capacity | Up to 512 clients per radio; up to 16 BSSIDs per radio |
| Ethernet Ports | (1) 2.5 GbE (PoE) RJ-45, (1) 1 GbE SFP |
| Power Input | IEEE 802.3bt PoE or direct DC (optional PSU) |
| Max Power Consumption | Up to 45.5W |
| Mounting | Integrated mounting bracket (kits sold separately) |
| Security Features | WPA3, Enhanced Open, TPM, PEF, Dynamic Segmentation |
| Environmental Rating | Weatherproof, temperature hardened, hazardous location-ready |
| Certifications | Wi-Fi Alliance, Bluetooth SIG, Ethernet Alliance, FCC, CE, RED, EN 60601-1 |
| Special Features | Embedded GPS, Target Wake Time (TWT), Advanced IoT Coexistence (AIC) |
