Description
The HPE Aruba Networking AP‑675 (JP) is a high-performance tri-radio Wi-Fi 6E access point engineered for challenging outdoor environments. As part of the 670 Series, this model leverages the newly available 6 GHz spectrum to deliver up to 3.9 Gbps aggregate throughput using tri-radio 2x2:2 MIMO. With internal omni-directional antennas, a ruggedized weatherproof design, integrated GPS, and high-power Bluetooth and Zigbee radios, it's ideal for industrial IoT, smart campuses, and remote site deployments.
Equipped with a 2.5 GbE port, 1 GbE SFP fiber port, and advanced features like ClientMatch, Dynamic Segmentation, and target wake time (TWT), the AP-675 ensures seamless connectivity, improved efficiency, and enhanced security.
| Specification | Details |
|---|---|
| Product Number | S0P52A |
| Model | AP‑675 (JP) |
| Antenna Type | Internal Omni-Directional |
| Wi-Fi Standard | Wi-Fi 6E (IEEE 802.11ax), Tri-Radio (2.4GHz / 5GHz / 6GHz) |
| MIMO | 2x2:2 on all radios |
| Max Data Rate | Up to 3.9 Gbps aggregate |
| BLE/Zigbee | Integrated with 4.5 dBi gain antenna |
| GPS | Embedded GPS receiver |
| Ethernet Ports | (1) 10/100/1000BASE-T RJ-45, (1) 1 GbE SFP Fiber |
| Input Power | IEEE 802.3bt PoE or DC input (optional power supply) |
| Power Consumption | Up to 45.5W |
| Mounting | Integrated bracket; compatible with optional mounting kits |
| Max Clients per Radio | 512 clients |
| BSSID per Radio | Up to 16 (8 max on 6GHz) |
| Temperature Hardened | Yes – Outdoor-rated, Ruggedized |
| Dimensions | Not specified (refer to QuickSpecs) |
| Certifications | Wi-Fi Alliance, Bluetooth SIG, Ethernet Alliance |
| Compliance | FCC/ISED, CE, RED, EMC, LVD, EN 60601 series |
| Warranty | Limited lifetime warranty |
