Description
Ruggedized High-Performance Wi-Fi 6E for Harsh Outdoor Environments
The HPE Aruba Networking AP‑675 (JPF1) is a tri-radio Wi‑Fi 6E outdoor access point, purpose-built for environmentally challenging and high-density enterprise or industrial IoT environments. It delivers up to 3.9 Gbps aggregate throughput with advanced features such as integrated omnidirectional antennas, embedded GPS, and support for Bluetooth and Zigbee connectivity.
With Wi-Fi 6E support across 2.4GHz, 5GHz, and 6GHz bands, the AP-675 offers greater capacity, lower latency, and more spectrum to meet the demands of bandwidth-hungry applications such as high-definition video and AR/VR. Featuring secure segmentation, rugged weatherproof construction, and optional AFC (Automated Frequency Coordination), this TAA-compliant access point ensures reliable and secure outdoor wireless performance.
| Specification | Details |
|---|---|
| Product Number | S0Q37A |
| Model | AP‑675 (JPF1) |
| Wi-Fi Standard | Wi‑Fi 6E (802.11ax) |
| Radios | Tri Radio (2.4GHz, 5GHz, 6GHz) – 2x2 MIMO each |
| Max Data Rate | Up to 3.9 Gbps aggregate |
| Antenna Type | Internal omnidirectional antennas |
| Antenna Gain | 2.4GHz: 3.8 dBi 5GHz: 5.7 dBi 6GHz: 5.9 dBi BLE/Zigbee: 4.5 dBi |
| Bluetooth/Zigbee | Integrated high-power radios |
| Ports | (1) 2.5GBASE-T RJ-45, (1) 1G SFP |
| Power Options | IEEE 802.3bt PoE or optional DC power supply |
| Power Consumption | Up to 45.5W |
| Mounting | Preinstalled mounting bracket (kits sold separately) |
| Client Capacity | Up to 512 clients per radio; up to 16 BSSIDs per radio (8 on 6GHz) |
| Security | WPA3, Enhanced Open, TPM, PEF, Dynamic Segmentation |
| Environmental Rating | Outdoor, weatherproof, temperature hardened |
| Special Features | Embedded GPS, Intelligent Power Monitoring, Advanced IoT Coexistence |
| Certifications | Wi-Fi Alliance, Bluetooth SIG, TAA, CE, FCC/ISED, EMC/RED/Low Voltage Directives |
| Warranty | Limited lifetime warranty |
