Description
Bring high-performance Wi-Fi 6E to the outdoors with the HPE Aruba Networking AP‑675 (EGF1). Purpose-built for harsh, environmentally challenging locations, this tri-radio 2x2:2 outdoor access point delivers up to 3.9 Gbps aggregate throughput, utilizing the 6 GHz band to dramatically increase wireless capacity and performance.
With integrated high-power Bluetooth and Zigbee radios, embedded GPS, and dual Ethernet ports (2.5 GbE and 1 GbE SFP), the AP-675 enables robust, secure, and intelligent wireless connectivity for enterprise and industrial IoT environments. Built-in omni-directional antennas ensure strong coverage, while Dynamic Segmentation, WPA3 security, and TPM-based credential protection ensure the integrity and safety of your network.
Perfect for campus-wide wireless deployments, industrial zones, and critical infrastructure, the AP-675 ensures reliability and control even in the most demanding outdoor environments.
| Specification | Details |
|---|---|
| Model Number | AP‑675 (EGF1) |
| Part Number | S0Q39A |
| Wi-Fi Standard | Wi-Fi 6E (IEEE 802.11ax), Tri Radio 2x2:2 MIMO |
| Maximum Data Rate | Up to 3.9 Gbps |
| Radio Bands | Concurrent 2.4 GHz, 5 GHz, and 6 GHz |
| Antenna Type | Internal Omni-Directional Antennas |
| Antenna Gain | 2.4 GHz: 3.8 dBi, 5 GHz: 5.7 dBi, 6 GHz: 5.9 dBi |
| IoT Radios | Integrated Bluetooth and Zigbee (up to 4.5 dBi) |
| Ethernet Ports | (1) 2.5 GbE RJ-45, (1) 1 GbE SFP port |
| Power Options | IEEE 802.3bt PoE or direct DC (via optional power supply) |
| Power Consumption | Up to 45.5W |
| Mounting | Preinstalled bracket for optional mounting kits |
| Client Capacity | Up to 512 clients per radio; 16 BSSIDs per radio (8 max on 6 GHz) |
| Security Features | WPA3, Enhanced Open, TPM, Policy Enforcement Firewall (PEF) |
| Rugged Features | Weatherproof, temperature-hardened, supports hazardous environments |
| Location Awareness | Embedded GPS Receiver |
| Certifications | Wi-Fi Alliance, Bluetooth SIG, TAA Compliant |
| Regulatory | FCC/ISED, CE Mark, RED, EMC, LVD, IEC/EN 62368-1 |
| Warranty | Limited Lifetime Warranty |
