Description
High-Performance Wi‑Fi 6E for Harsh Outdoor Environments
The HPE Aruba Networking AP-677 (EGF1) is a tri-radio Wi-Fi 6E outdoor access point designed to deliver ultra-reliable, high-speed wireless connectivity in extreme environments. Featuring internal directional antennas, this TAA-compliant unit operates across 2.4GHz, 5GHz, and 6GHz bands, achieving aggregate data rates of up to 3.9 Gbps.
Ideal for demanding enterprise and industrial IoT applications, the AP-677 supports wide 160 MHz channels in the 6 GHz band to accommodate bandwidth-intensive and low-latency applications such as AR/VR and high-definition video.
Built with rugged weatherproof housing, embedded GPS, high-power Bluetooth and Zigbee radios, dual Ethernet ports (2.5GbE + SFP), and advanced security with WPA3 and TPM, this access point ensures performance, scalability, and protection where you need it most.
| Specification | Details |
|---|---|
| Product Number (SKU) | S0Q40A |
| Model Name | AP‑677 (EGF1) |
| Wi-Fi Standard | IEEE 802.11ax (Wi-Fi 6E), tri-radio |
| MIMO Configuration | 2x2:2 MIMO per band (2.4GHz / 5GHz / 6GHz) |
| Max Data Rate | Up to 3.9 Gbps aggregate |
| Antenna Type | Internal Directional Antennas |
| Antenna Gain | 2.4GHz: 6.9 dBi, 5GHz: 6.5 dBi, 6GHz: 6.9 dBi |
| IoT Radios | Integrated high-power Bluetooth and Zigbee (peak gain: 4.5 dBi) |
| Ports | (1) 2.5G RJ-45, (1) 1G SFP fiber port |
| Mounting | Pre-installed bracket for mount kits (sold separately) |
| Power Options | IEEE 802.3bt PoE or direct DC (via optional PSU) |
| Power Consumption | Up to 45.5W max |
| Client Capacity | Up to 512 clients per radio |
| BSSID Support | Up to 16 BSSIDs per radio (6GHz limited to 8) |
| GPS | Embedded GPS receiver |
| Security | WPA3, Enhanced Open, TPM, Policy Enforcement Firewall (PEF), Dynamic Segmentation |
| Certifications | Wi-Fi Alliance, Bluetooth SIG, Ethernet Alliance, FCC, CE, TAA |
| Operating Conditions | Weatherproof, hardened for hazardous outdoor environments |
| Warranty | Limited lifetime warranty |
