Description
The HPE Aruba Networking AP-677 (ILF1) is a high-performance, tri-radio outdoor access point designed to bring the full power of Wi-Fi 6E to rugged and environmentally challenging locations. Ideal for enterprise and industrial IoT deployments, this TAA-compliant AP supports the 6 GHz band, delivering ultra-fast speeds and increased capacity.
Engineered with internal directional antennas, this weatherproof AP is equipped with high-power Bluetooth and Zigbee radios for advanced IoT integration, along with embedded GPS for self-location. It offers fast wired connectivity via a 2.5 GbE port and 1 GbE SFP uplink, and supports up to 3.9 Gbps aggregate data rate across the 2.4 GHz, 5 GHz, and 6 GHz bands.
With intelligent power monitoring, robust security features like WPA3, TPM, and Policy Enforcement Firewall (PEF), and support for up to 512 clients per radio, the AP-677 is a future-proof solution for high-density outdoor networking needs.
| Specification | Details |
|---|---|
| Product Number | S0Q41A |
| Wi-Fi Standard | Wi-Fi 6E (802.11ax) |
| Radios | Tri Radio (2.4GHz, 5GHz, 6GHz) |
| Antenna Type | Internal directional antennas |
| Antenna Gain | 2.4 GHz: 6.9 dBi5 GHz: 6.5 dBi6 GHz: 6.9 dBiBLE/Zigbee: 4.5 dBi omnidirectional |
| Maximum Data Rate | Up to 3.9 Gbps aggregate |
| MIMO | 2x2:2 MIMO for each band |
| Bluetooth / Zigbee | Integrated high-power radios |
| Client Capacity | Up to 512 clients per radio |
| Ports | (1) 2.5GBASE-T RJ-45(1) 1G SFP fiber port |
| Power Input | IEEE 802.3bt PoE or DC (optional power supply) |
| Power Consumption | Up to 45.5W |
| Mounting | Pre-installed bracket (mount kits sold separately) |
| Location Services | Embedded GPS for auto location |
| Security | WPA3, Enhanced Open, TPM, Policy Enforcement Firewall |
| Compliance | TAA, FCC, CE, RED, EMC, IEC/EN 62368-1, etc. |
| Operating Environment | Outdoor, temperature-hardened, weatherproof |
| Warranty | Limited lifetime warranty |
