Description
Deliver reliable and cost-effective Wi-Fi 6 coverage for indoor environments with the HPE Aruba Networking AP-503 (US) 10-Pack. Designed for medium-density deployments such as offices, schools, and retail spaces, the AP-503 provides up to 1.49 Gbps combined throughput with support for OFDMA, MU-MIMO, and WPA3 security.
This compact access point supports 2x2:2 MIMO and operates on both 2.4 GHz and 5 GHz bands, offering seamless performance for multiple Wi-Fi 6 clients. With flexible cloud management via HPE Aruba Networking Central, it simplifies IT operations, ensures secure access with Dynamic Segmentation, and supports optional Bluetooth 5 and Zigbee connectivity through an expansion module.
Sold in an eco-friendly 10-pack, the AP-503 is perfect for growing campuses or businesses looking to expand their wireless coverage efficiently and affordably.
| Specification | Details |
|---|---|
| Product Number | S1E84A |
| Form Factor | Indoor, dual-radio access point |
| Wi-Fi Standard | IEEE 802.11ax (Wi-Fi 6), backward compatible |
| Radio Configuration | 2x2:2 MIMO on both 2.4 GHz and 5 GHz |
| Max Data Rate | 1.49 Gbps (combined) |
| Antenna Type | Integrated omni-directional antennas (1.7 dBi @ 2.4GHz, 4.8 dBi @ 5GHz) |
| Management | HPE Aruba Networking Central (AI-powered) |
| Security Features | WPA3, Enhanced Open, Dynamic Segmentation, TPM |
| Ports | 1x RJ-45 Ethernet (E0), 1x USB 2.0 (Type A), 1x Console (Micro-B USB) |
| IoT Support | Optional Bluetooth 5 & Zigbee via expansion module |
| Mounting Options | Optional mounting kits available |
| Certifications | Wi-Fi CERTIFIED 6, WPA3, FCC, CE, RED, UL/IEC/EN 62368-1 |
| Dimensions | 3.5 x 14.5 x 14.5 cm |
| Weight | 255 g |
| Warranty | Limited lifetime warranty |
| Pack Configuration | 10-Pack (US only) |
